Features: • 1 x Gigabit PoE++ input port
• 4 x Gigabit PoE+ output ports
• 60W PoE power budget with PoE++ Type 4 (90W) input power
• Easy-to-use web-based management interface
• Supports RSTP, VLAN, QoS, and IGMP Snooping
• Voice VLAN for VoIP applications
• Bandwidth control per port
• 10Gbps switching capacity
• Compact fanless design
• Wall-mountable metal housing
• NDAA / TAA compliant (U.S. and Canada only)
• Lifetime
Primary Ports: 8 x Gigabit PoE+ ports
2 x SFP Slots
LED indicators
LED Display mode button (toggles LED indicators to display link/activity or PoE only port status)
Features: • 8 x Gigabit PoE+ ports
• 2 x SFP ports
• Supports 100/1000Base-FX fiber SFP modules
• PoE power budget: 240W@48VDC or 124W@24VDC
• PoE alive check restarts unresponsive PoE powered devices
• 20Gbps switching capacity
• Hardened IP40 rated metal housing
• Includes DIN-Rail mounting bracket
• Operating temperature range of -40° – 75° C (-40° – 167° F)
• Supports LACP, STP/RSTP, VLAN, and IGMP Snooping
• IEEE 802.1p QoS with queue scheduling support
• Bandwidth control per port
• Redundant power inputs with overload current protection
• Alarm output triggered by power failure
• Power supply sold separately (models: TI-S24048, TI-S48048, TI-S24052, TI-S15052)
• NDAA / TAA compliant (U.S. and Canada only)
• Lifetime Warranty
Network Media: WAN Modes: NAT, Classical Routing or Bridge Mode (NAT Disabled)
NAT Loopback Enable/Disable
NAT Modes: NAT, PAT, One-to-One NAT
VLAN tag assignment on WAN interface
IPv4 WAN Modes: Dynamic IP (DHCP), Static IP, PPPoE, PPTP, L2TP
Wireless WAN Mode: NAT enable/disable, Dynamic IP (DHCP), Static IP, fast roaming signal threshold/channels
IPv6 WAN Modes: Static, Auto-configuration (SLAAC/DHCPv6),...
Features: • 8 x Gigabit PoE+ ports
• 64W PoE power budget
• Easy-to-use web-based management interface
• Supports static link aggregation, RSTP, VLAN, QoS, and IGMP Snooping
• Voice VLAN for VoIP applications
• Bandwidth control per port
• 16Gbps switching capacity
• IEEE 802.1p CoS with queue scheduling support
• Compact fanless design
• Wall mountable metal housing
•
Features: • 1 x 10G PoE++ port (Data + PoE out)
• 1 x 10G port (Data in)
• 120W PoE power budget
• Supports PoE (15.4W), PoE+ (30W), and PoE++ (95W) devices
• Uses IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt industry PoE standards for greater device interoperability
• Network a PoE device located up to 100m (328 ft.)
• Fanless design eliminates operating noise and lowers energy consumption
• Extreme operating temperature range -40° – 75° C (-40° – 167° F)
• Includes DIN-Rail mount and wall mount
• Power supply sold separately (model: TI-S15052)
• NDAA / TAA compliant (U.S. and Canada only)
Features: 8 x Gigabit PoE++ ports
2 x Gigabit SFP ports
240W PoE power budget
20Gbps switching capacity
Fast PoE minimizes wait time for powering up PoE devices
Support VLAN pass through
Internal power supply
Sturdy 1U 19” rack mountable metal housing
NDAA / TAA compliant (U.S. and Canada only)
Lifetime Warranty
