Changer Type: Type-C to MiniDP Adapter:
Chipset: Cypress CYPD1120
Signal input: USB 3.1 Type-C male
Signal output: Active MiniDP female
Support DP version: V1.2
DP port resolution support: Up to 4096 x 2160 (4K x 2K) (DisplayPort Alt mode)
MiniDP to HDMI Adapter:
Chipset: Chrontel CH7525
Signal input: MiniDP Male
Signal output: HDMI female (HDMI V1.4)
HDMI port Resolution support: Up to 4096 x 2160 (4K x 2K) at 30Hz
HDMI to VGA Adapter:
Chipset: Chrontel CH7101B
Signal input: HDMI male
Signal output: VGA female
VGA port Resolution support: Up to 1920 x 1200 at 60Hz
Specifications: Maximum Digital Resolutions: 3840 x 2160 @ 60Hz
Supported Resolutions:
3840 x 2160 @ 60Hz
2560 x 1600
2048 x 1280
1920 x 1200
1920 x 1080
1280 x 720
1680 x 1050
1600 x 900
1440 x 900
1360 x 768
1280 x 800
1280 x 768
Wide Screen Supported:Yes
Humidity: 0~90% RH
Operating Temperature: 0 C to 40 degree C
Storage Temperature: -20C to 70 degree C
Output Connector: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
1 x DisplayPort (20 pin) Female Output
Specifications: 15 ft. USB-C to DisplayPort Cable - 4K 60Hz
The USB-C to DisplayPort cable provides a solution to connect USB-C devices that support DisplayPort alternate mode (DP alt mode) to DisplayPort displays. The 6 feet length efficiently connects MacBooks, Chromebooks, and other USB-C devices that support DisplayPort Alternate Mode (DP Alt Mode) to displays without needing an additional DisplayPort cable.
4K / 60Hz Resolution
Support for resolutions up to 4K / 60Hz allow you to output onto 4K monitors to display Ultra HD resolutions up to 3840x2160 / 60Hz. Perfect for streaming HD content and playing Blu-ray media. The 6ft length also provides a longer length for use with a wide variety of setups. The DisplayPort male end also eliminates the ...
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID: Genesys Logic - GL3523 (USB Hub), Realtek - RTL8153 (LAN), Parade Technologies - PS176 (HDMI)
Displays Supported: 1
Fast-Charge Port(s): No
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type: 1 - USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8, 8.1, 10 / Mac OS 10.10 to 10.12 / Chrome OS
Note:
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your laptop USB-C port supports DP alt mode.
A 4K-capable display is required to achieve 4K x 2...
Specifications: Converter Type: Format Converter
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 3840 x 2160 (Ultra HD 4K) @ 60hz
Supported Resolutions: 1024 x 768, 1280 x 720, 1920 x 1080, 1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
Connector Type(s): 1 x USB Type-C (24 pin) USB 3.0 Female
System and Cable Requirements: Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
Humidity: 25% to 85% RH Non-Condensing
Operating Temperature: 5 to 35 degree C (41 to 95 degree F)
Storage Temperature: 5 to 35 degree C (41 to 95 degree F)
