Specifications: LEDs indicate the status of the HDMI device, the HDMI displays & the Splitter
All ports conveniently on back of Splitter
Supports 1080P/1080i/720P/576P/576i/480P/ 480i resolutions
Supports 3D & Deep Color up to 36-bit
Supports Dolby True HD, DTS-HD master audio, CEC-enabled units & HDCP repeaters
Front Panel:
4 LED Indicators
Reset Button
Power LED Indicator
Back Panel:
4x HDMI Output Female Ports
1x HDMI Input Female Port
DC5V Power Input Jack
Metal casing
Package Contents: VGA Extender Transmitter
VGA Extender Receiver
VGA Cable
3.5mm Cable
3.5mm to IR Receiver Cable
3.5mm to IR Blaster Emitter Cable
RS-232 to 3.5mm Adapter Cable
AC Power Adapter (x2) (5V / 2A)
User Manual
Specifications: Chip: FT232RL + ZT213 British import best guarantee compatibility
The CONSOLE port (used for computer USB turn RJ45)
General network devices have a CONSOLE interface, this interface is used to set or more of the underlying operating equipment.
Supports USB 1.0, 1.1, and 2.0
Used for CISCO routers and switches and AP wireless router
Apply to WIN 7 32 bit, Windows 7 64 - bit, Windows XP MAC Ann table, etc
