Specifications: VE803T
Connectors
HDMI In: 1 x HDMI Type A Female (Black)
USB: 1 x USB Type B Female (White)
HDMI/USB Port: 2 x RJ-45 Female (Silver)
Power: 1 x DC Jack
Switches:
EDID Selection: 1 x slide switch
LEDs
Power: 1 (Green)
Video:
1080p @ 60Hz, at 40m
1080i @ 60Hz, at 60m
Power Consumption: DC5V, 1W
PhysicalProperties
Housing: Metal
VE803R
Connectors
HDMI Out: 1 x HDMI Type A Female (Black)
USB: 1 x USB Type A Female(White)
HDMI/USB Port: 2 x RJ-45 Female (Silver)
Power: 1 x DC Jack
Switches
EQ Compensation: 1 x 8 position switch
LEDs
Power: 1 (Green)
HDMI: 1 (Green)
USB: 1 (Green)
Video:
1080p @ 60Hz, at 40m
1080i @ 60Hz, at 60m
Power Consumption: DC5V, 3.9W
PhysicalProperties
Housing: Metal
Specifications: Interfaces
Relay
8 normally open relays (8 x 2-pole terminal block)
Contact Rating: Max 24 VDC, 2A
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A (Firmware upgrade only)
Power
Consumption 5 VDC, 10 W (Adapter); 48 VDC, 13 W (PoE, PoE 802.3 AF/AT compatibility)
Output 12 VDC, 300 mA
