Max Extend Distance: Long range transmission:up to 20 km over a single-mode/Multi-mode LC fiber optic cable;
Specifications: 1080P 120Hz HDMI Extender HDMI Over Fiber Converter 4K@60HZ Video Optical Transceiver LC Single Mode 20km Multimode10G SFP
Video
Standards----------HDMI 2.0b; HDCP 2.2
Maximum pixel clock------600MHz
Maximum data rate-------18Gbps
Resolution ------3840X2160P@60Hz
Connector-----HDMI-A
Fiber type
Fiber interface--------------- LC Connector
Transmission distance--------0~20 km over single/multi-mode fiber
Fiber Type---------- ------------------ Single Mode
Wavelength--------------------1310nm 1510nm
Interface Bandwidth--------------18Gbps
Other
Power supply-----The power adapter: DC 5V/2A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------104*98*23mm
The warranty----...
Specifications: Audio: Yes
Chipset ID: STDP4320
Converter Type: MST Hub
Output Signal: HDMI
Ports: 2
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions:
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.
Average resolution bandwidth allocation
1920 x 1080 (High-definition 1080p) @60 Hz - 22%
1920 x 1200 @60hz - 30%
2560 x 1440 @60hz - 35%
2560 x 1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30 Hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Specifications: Approvals: CE, RoHS2, WEEE, UL
Connectors : (1) screw lock barrel power connector, (1) USB mini for power and FW upgrades; Input: (3) component video (one is used for composite), (2) 3.5-mm L/R audio, (1) SPDIF audio; Output: (1) HDMI video
Humidity 10% tp 90%, non-condensing
Maximum Altitude: 10,000 feet
Operating Temperature: 32º to 122º F (0 to 50ºC)
Power Source: wallmount style power supply, USB mini (not included); Input: 100–24- VAC, 50/60 Hz, 1.5 Amp; Output: 5 VDC 2A barrel plug
Storage Temperature: -40º to 158ºF (-40 to 70ºC)
User Controls : (3) push buttons
