Specifications: • Standard 2.5" IDE storage device form factor (100.2mm x 69.9mm x 9.8mm)
• LED indicators: Power On, Master and Slave Card Detect, and Disk Activity
• Can be a primary bootable device containing the OS and applications (depends on CF card specifications)
• Transparent to operating system and does not require any drivers
• Supports Microsoft Windows 2000, XP 32/64-bit, Server 2003 32/64-bit, Vista 32/64-bit, Server 2008 32/64-bit and Linux operating systems
• Power supply via IDE interface (44-pin SFF IDE connector, +5V)
IDE Interface
• 44-pin SFF (Small Form Factor) IDE connector
• Supports Ultra-DMA IDE Interface
• Does not support hot swap on the IDE interface
CF Interface
• 2 CF card slots (Master/Slave) supporting CF Type I form factor
• Supports PIO mode, DMA and Ultra-DMA mode with data transfer rate u...
Specifications: Adapter:
Device Support: SATA III/II/I SSD/HDD
Device Size: 2.5" SSD/HDD
SATA Interface: Standard SATA
USB Interface: USB 3.0 Type A (Backwards Compatible with USB 2.0)
HDD Capacity: Up to 2TB (Check www.vantecusa.com for any updates)
Material: Plastic
Power: USB Bus Powered
Casing:
Device Support: SATA III/II/I SSD/HDD
Device Size: 2.5", Thickness: 9.5mm
Material: Plastic
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10
Mac OS X v10.4 and Up
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
For UASP, the OS must have Support for UASP Protocol
