Specifications: Max Distance: 150 m / 500 ft
Supported Resolutions:
1600x1200 @ 150ft(50m)
1280x1024 @ 300ft(100m)
1024x768 @ 500ft(150m)
The ST1218T 8 Port VGA Video Extender over Cat 5 is designed for use with our ST121 VGA over Cat 5 extension series, offering convenient VGA video distribution at distances of up to 492 feet (150 meters) using standard Cat 5 (or better) cabling.
Comprised of the transmitter unit only, the ST1218T requires one Receiver Unit (ST121R) per display that you are connecting.
For added versatility, the VGA over Cat 5 Repeater (ST121EXT) can be used to extend the distance between the transmitter and receiver by an additional 492-feet (150 meters), for a total distance of 984-feet (300 meters). Similarly, up to 3 repeater units can be used betwe...
Specifications: NEW 60M HDMI Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 LAN Extensor
Video
Standards----------HDMI 1.4; HDCP 1.4
Maximum pixel clock------165MHz
Maximum data rate-------10.2Gbps
Resolution ------1920X1080P@60Hz
Connector-----HDMI-A
Impedance--------100O
UTP
Interface-----RJ45/ IEEE-568B
distance--------CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply-----The power adapter: DC 5V/1A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------94*71*25mm
The warranty--------1 year free warranty
Specifications: NEW 60M HDMI Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 LAN Extensor
Video
Standards----------HDMI 1.4; HDCP 1.4
Maximum pixel clock------165MHz
Maximum data rate-------10.2Gbps
Resolution ------1920X1080P@60Hz
Connector-----HDMI-A
Impedance--------100O
UTP
Interface-----RJ45/ IEEE-568B
distance--------CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply-----The power adapter: DC 5V/1A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------94*71*25mm
The warranty--------1 year free warranty
Specifications: Video
Standards: HDMI 1.3; HDCP 1.2
Maximum pixel clock: 165MHz
Maximum data rate: 6.75Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
IR
Interface: 3.5mm seat
Signal direction: directional
Signal type: Digital
IR frequency: 20~60 KHz ;
UTP
Interface: RJ45/IEEE-568B
Transmission distance: CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply: The power adapter: DC 5V/1A
Power dissipation: MAX 3W
Temperature: Operating: -5? ~ +70?
Humidity: Operating: 5% ~ 90%
Dimension: 94*71*25mm
The warranty: 1 year free warranty
Specifications: 1. HDMI resolution supports: 1080p@50/60Hz, 1080i@50/60Hz, 720p@50/60Hz, 576p@50Hz, 576i@50Hz, 480p@60Hz, 480i@60Hz
2. Audio format supports: DTS-HD/D o l b y-trueHD/DTS/D o l b y-AC3/ DSD.
4. Supports 3D(Note: To get 3D, all units connected to the extender must support 3D)
5. Transmission bandwidth: 1.65Gbps
6. HDMI cable length: AWG26 HDMI cable up to 8.0 meters(xx ft)
7. Power Supply: DC 5V/1A(2pcs)
Specifications: Video
Standards: HDMI 1.3; HDCP 1.2
Maximum pixel clock: 165MHz
Maximum data rate: 6.75Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
IR
Interface: 3.5mm seat
Signal direction: directional
Signal type: Digital
IR frequency: 20~60 KHz ;
UTP
Interface: RJ45/IEEE-568B
Transmission distance: CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply: The power adapter: DC 5V/1A
Power dissipation: MAX 3W
Temperature: Operating: -5? ~ +70?
Humidity: Operating: 5% ~ 90%
Dimension: 94*71*25mm
The warranty: 1 year free warranty
Specifications: NEW 60M HDMI Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 LAN Extensor
Video
Standards----------HDMI 1.4; HDCP 1.4
Maximum pixel clock------165MHz
Maximum data rate-------10.2Gbps
Resolution ------1920X1080P@60Hz
Connector-----HDMI-A
Impedance--------100O
UTP
Interface-----RJ45/ IEEE-568B
distance--------CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply-----The power adapter: DC 5V/1A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------94*71*25mm
The warranty--------1 year free warranty
Specifications: NEW 60M HDMI Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 LAN Extensor
Video
Standards----------HDMI 1.4; HDCP 1.4
Maximum pixel clock------165MHz
Maximum data rate-------10.2Gbps
Resolution ------1920X1080P@60Hz
Connector-----HDMI-A
Impedance--------100O
UTP
Interface-----RJ45/ IEEE-568B
distance--------CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply-----The power adapter: DC 5V/1A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------94*71*25mm
The warranty--------1 year free warranty
Specifications: NEW 60M HDMI Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 LAN Extensor
Video
Standards----------HDMI 1.4; HDCP 1.4
Maximum pixel clock------165MHz
Maximum data rate-------10.2Gbps
Resolution ------1920X1080P@60Hz
Connector-----HDMI-A
Impedance--------100O
UTP
Interface-----RJ45/ IEEE-568B
distance--------CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply-----The power adapter: DC 5V/1A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------94*71*25mm
The warranty--------1 year free warranty
Specifications: NEW 60M HDMI KVM Over Network Extender 4K 60Hz HDMI Transmitter by RJ45 CAT5e CAT6 Extensor Support KVM remote control
Video
Standards: HDMI 2.0; HDCP 2.2 and DVI compliant
Maximum pixel clock: 300MHz
Maximum data rate: 18Gbps
Resolution: 3840 x 2160@60Hz
Connector: HDMI-A
Impedance: 100O
?
Package Contents: HDMI KVM extender transmitter x1
HDMI KVM extender receiver x1
Power adapter x1
User manual x1
Specifications: Cabling: Cat 5 UTP or better
Ports: 1
Max Distance: 50 m / 165 ft
Maximum Data Transfer Rate: 480Mbps
MTBF: 72,000 Hours
OS Compatibility: OS Independent; No additional drivers or software required
System and Cable Requirements:
A host computer with an available USB-A port (USB Type-A)
Terminated RJ45 Cat5e or better Ethernet cable
LED Indicators: 1 x Power / Link
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 100 - 240 AC
Output Current: 2 A
Output Voltage: 5 DC
Plug Type: N
Power Consumption (In Watts): 10
Power Source: AC Adapter Included
Enclosure Type: Steel
Specifications: 1. HDMI resolution supports: 1080p@50/60Hz, 1080i@50/60Hz, 720p@50/60Hz, 576p@50Hz, 576i@50Hz, 480p@60Hz, 480i@60Hz
2. Audio format supports: DTS-HD/D o l b y-trueHD/DTS/D o l b y-AC3/ DSD.
4. Supports 3D(Note: To get 3D, all units connected to the extender must support 3D)
5. Transmission bandwidth: 1.65Gbps
6. HDMI cable length: AWG26 HDMI cable up to 8.0 meters(xx ft)
7. Power Supply: DC 5V/1A(2pcs)
Specifications: Length of CAT-5E/CAT-6 cable between Rx and TX: up to 120 meters
HDMI input and output : 4K/1080p/720p/576p/576i/480p/ 480i
Support audio format: DTS/Dolby/LPCM
Max bandwidth: 340MHz
Max baud rate: 10.2Gbps
Input HDMI cable distance: =15m AWG26 HDMI standard cable
Output HDMI cable distance: =15m AWG26 HDMI standard cable
TX Max working current: 350mA
RX Max working current : 200mA
Power adapter format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range: (-15 to +55?)
Specifications: Length of CAT-5E/CAT-6 cable between Rx and TX: up to 120 meters
HDMI input and output : 4K/1080p/720p/576p/576i/480p/ 480i
Support audio format: DTS/Dolby/LPCM
Max bandwidth: 340MHz
Max baud rate: 10.2Gbps
Input HDMI cable distance: =15m AWG26 HDMI standard cable
Output HDMI cable distance: =15m AWG26 HDMI standard cable
TX Max working current: 350mA
RX Max working current : 200mA
Power adapter format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range: (-15 to +55?)
Specifications: Length of CAT-5E/CAT-6 cable between Rx and TX: up to 120 meters
HDMI input and output : 4K/1080p/720p/576p/576i/480p/ 480i
Support audio format: DTS/Dolby/LPCM
Max bandwidth: 340MHz
Max baud rate: 10.2Gbps
Input HDMI cable distance: =15m AWG26 HDMI standard cable
Output HDMI cable distance: =15m AWG26 HDMI standard cable
TX Max working current: 350mA
RX Max working current : 200mA
Power adapter format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range: (-15 to +55?)
Specifications: Video
Standards: HDMI 1.3; HDCP 1.2
Maximum pixel clock: 165MHz
Maximum data rate: 6.75Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
IR
Interface: 3.5mm seat
Signal direction: directional
Signal type: Digital
IR frequency: 20~60 KHz ;
UTP
Interface: RJ45/IEEE-568B
Transmission distance: CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply: The power adapter: DC 5V/1A
Power dissipation: MAX 3W
Temperature: Operating: -5? ~ +70?
Humidity: Operating: 5% ~ 90%
Dimension: 94*71*25mm
The warranty: 1 year free warranty
