Specifications: Cabling: Cat 5 UTP or better
Ports: 1
Max Distance: 50 m / 165 ft
Maximum Data Transfer Rate: 480Mbps
MTBF: 72,000 Hours
OS Compatibility: OS Independent; No additional drivers or software required
System and Cable Requirements:
A host computer with an available USB-A port (USB Type-A)
Terminated RJ45 Cat5e or better Ethernet cable
LED Indicators: 1 x Power / Link
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 100 - 240 AC
Output Current: 2 A
Output Voltage: 5 DC
Plug Type: N
Power Consumption (In Watts): 10
Power Source: AC Adapter Included
Enclosure Type: Steel
Specifications: Video Input: Displayport (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 1
Video Ports: (2) HDMI (FEMALE)
Video Ports Details: DisplayPort 1.2a; HDMI 2.0; HDCP 1.4; HDCP 2.2
Resolutions Supported: 3840 x 2160 (4K x 2K) @ 60 Hz (both Local HDMI port and HDMI Output)
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Audio Ports: HDMI (FEMALE)
Audio Ports Details: HDMI outputs support passthrough audio formats including LPCM2.0/5.1/7.1
Audio Input: Displayport
Audio Output: HDMI
Audio Specification: Pass-through of Audio format includes LPCM2.0/5.1/7.1
Specifications: Audio: Yes
Cabling: Cat 5e UTP or better
Daisy-Chain: Yes
Rack-Mountable: Yes
Audio Specifications: 7.1 Channel Surround
Max Distance: 100 m / 330 ft
Maximum Digital Resolutions: 1920x1080 @60Hz
Supported Resolutions:
1920 x 1080 @60Hz
1280 x 720
1680 x 1050
1600 x 900
1440 x 900
1360 x 768
1280 x 800
1280 x 768
Lower resolutions and refresh rates may also be supported
Wide Screen Supported Yes
Specifications: Audio: Yes
AV Input: HDMI
AV Output: HDMI
Cabling: Cat 6 UTP
Chipset ID: Norelsys NS 5730, NS5731
Audio Specifications: 7.1 Surround Sound
Max Distance: 140 m / 460 ft
Wide Screen Supported: Yes
Supported Resolutions:
3840x2160 (4K) 60Hz
2560x1600 60Hz
1920x1200 60Hz
1920x1080 (1080p) 60Hz
1280x720 (720p) 60Hz
*Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Center Tip Polarity: Positive
Input Voltage: 110V-240V AC
Output Current: 3 A
Output Voltage: 5V DC
Plug Type: M
Power Source: 2 AC Adapters Included
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 2
Video Ports : (2) RJ45 (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 1.4; HDCP 2.2
Resolutions Supported : 3840 x 2160 (4K x 2K) @ 60 Hz
Max Supported Video Resolution: 3840 x 2160 (4K x 2K) @ 60 Hz
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Video Ports: HDMI (FEMALE); (4) RJ45 (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 2.2
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Audio Specification: True uncompressed 7.1 Channel digital audio and supports DTS-HD, Dolby-TrueHD digital audio
Specifications: Interfaces
Serial
4 x Programmable Bi-directional RS-232/422/485 Port
(4 x DB9 Male Connector, configurable via pin assignments);
Baud Rate: 300 to 115200 (default: 9600);
Data Bit: 8 (default) or 7;
Stop Bit: 1 (default) or 2;
Parity: None (default), Even or Odd;
Flow Control: None (default) RTS/CTS
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A
Power: Consumption 5 VDC, 7.5 W(adapter) ; 48VDC, 9.5 W(PoE, PoE 802.3 AF/AT compatibility)
Specifications: Audio: Yes
AV Input: HDMI
Cabling: Cat 5 UTP or better
Daisy-Chain: No
Ports: 1
Audio Specifications: Supports Dolby TrueHD, DTS-HD MA
IR Interface: Bi-directional, 38Khz / +/-10° / 5M
Max Distance: 50 m / 165 ft
Maximum Data Transfer Rate : HDMI - 3.4Gbps, RS232 - 115200bps baud
Maximum Digital Resolutions: 1080p @ 60Hz, 48-bit
Wide Screen Supported: Yes
