Specifications: Audio: Supports high-definition audio (HD) 5.1/6.1/7.1 surround sound: Dolby TrueHD, DTS-HD Master Audio LPCM channels up to 7.1 channels 192 kHz
Operating Humidity: 0 to 80% relative humidity
Operating Temperature: 32° to 122° F (0° to 50° C)
PoE: Complies with IEEE 802.3at standard, Class 4;
Power: Normal input: 48 VDC;
Input Range: 36 to 57 VDC
Power: (1) External 5 VDC, 3 A
Power Consumption: POE: 10.5 W
Storage Temperature: -4° to +140° F (-20° to +60° C)
User Controls:
B1: Set/Reset Pushbutton;
B2: Function Selection Pushbutton;
Rotary switch: Select from 16 Video Channels (HEX 0–F), Paired TX and RX units must use the same channel
Specifications: Length of CAT-5E/CAT-6 cable between Rx and TX: up to 120 meters
HDMI input and output : 4K/1080p/720p/576p/576i/480p/ 480i
Support audio format: DTS/Dolby/LPCM
Max bandwidth: 340MHz
Max baud rate: 10.2Gbps
Input HDMI cable distance: =15m AWG26 HDMI standard cable
Output HDMI cable distance: =15m AWG26 HDMI standard cable
TX Max working current: 350mA
RX Max working current : 200mA
Power adapter format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range: (-15 to +55?)
