Part Number: Input: 1 x USB 3.0 Cable 1 x HDMI 1 x VGA 2 x USB 3.0 1 x RJ45 Gigabit Ethernet Combo: 1 x SD Card Reader,1 x Micro SD Card Reader
Type: USB to DVI/VGA/HDMI
Color: Black
Features: Upstream USB3.0 foldable extension cable designed for Mini Dock handy travelling Built in HDMI port maximum resolution up to 2560x1600 and VGA port reach at 1080p Two USB-A ports extended USB3.0 (5Gbps) data transferring, and USB2.0 compliance Gigabit Ethernet with devices wake up function Combo built in USB3.0 SD and
Part Number: Input: 1 x USB 3.0 Cable1 x HDMI1 x VGA2 x USB 3.01 x RJ45 Gigabit EthernetCombo: 1 x SD Card Reader,1 x Micro SD Card Reader
Type: USB to HDMI Adapters
Color: Black
Features: Upstream USB3.0 foldable extension cable designed for Mini Dock handy travelling
Built in HDMI port maximum resolution up to 2560x1600 and VGA port reach at 1080p
Two USB-A ports extended USB3.0 (5Gbps) data transferring, and USB2.0 compliance
Gigabit Ethernet with devices wake up function
Combo built in USB3.0 SD and TF / Micro SD
Specifications: Chipset ID: MCT - Trigger 1+
Memory: 16MB SDRAM
USB Pass-Through: No
General Specifications: This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Supported Resolutions: Standard (1600 x 1200, 1400 x 1050, 1280 x 1024, 1280 x 960, 1152 x 864, 1024 x 768, 800 x 600) / Widescreen (1680 x 1050, 1440 x 900, 1280 x 800, 1280 x 768, 1152 x 864, 800 x 600)
Connector A: 1 x USB Type-A (4 pin) USB 2.0 Male Input
OS Compatibility: Windows 10 (32/64) / Windows 8 / 8.1 (32/64) / Windows 7(32/64) / Windows Vista (32/64) / Windows XP (32/64)
System and Cable Requirements: One available USB 2.0 port
Specifications: Audio: Yes
Chipset ID: T5-302/MCT
Output Signal: HDMI
USB Pass-Through: No
Audio Specifications: 2-Channel Stereo (48Khz)
General Specifications: This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset
Maximum Digital Resolutions: 1920 x 1200 / 1080p
Supported Resolutions:
Widescreen(16/32 bit):
1920 x 1200, 1920 x 1080, 1680 x 1050, 1600 x 900, 1440 x 900, 1360 x 768, 1280 x 800, 1280 x 768, 1280 x 720
Standard(16/32 bit):
1600 x 1200, 1400 x 1050, 1280 x 1024, 1280 x 960, 1152 x 864, 1024 x 768, 800 x 600
Connector A: 1 - USB Type-A (9 pin) USB 3.0 Male Input
Connector B: 1 - HDMI (19 pin) Female Output
Humidi...
Specifications: Host Interface: USB 3.0 Male Type-A Connector
Video Interface: 2 x HDMI Female Connector (HDMI Audio output simultaneously)
Max Resolution: 3840 x 2160 @ 30 Hz; 2048 x 1152 @ 60 Hz
Power Mode: Bus-powered
Power Consumption: = 400mA
Housing Material: Aluminum
Specifications: Maximum Data Transfer Rate: 5 Gbps (USB 3.0)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz / 3840 x 2160p @ 30Hz
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Output Connector: 1 x HDMI (19 pin) Female
1 x USB Type-A (9 pin) USB 3.0 Female
1 x USB Type-C (24 pin) USB 3.0 Female
Specifications: Audio Specifications: 7.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 or 1080p
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions: 1024 x 768, 1280 x 720 (High-definition 720p), 1920 x 1080 (High-definition 1080p), 1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160 (Ultra HD 4K)
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
Features: - Two video stream groups for dual display, each group only supports one to use simultaneously.
- Compatible with TBT4/3 and other USB-C Alt Mode ports on Mac or Windows computer.
- Supports mirror and extend modes.
- Boasts excellent heat dissipation capabilities and occupies minimal space, making it convenient to carry around.
Package Contents: 1x USB 3.0 to DP/HDMI Dual Display Adapter(cable length: 90mm/3.5in), 1x CD-Shaped Card for Driver Download Links, 1x Quick Start Guide
