Specifications: Chipset: DisplayLink DL-3900
Compliant with Universal Serial Bus 3.0 Specification
Compatible with both standard (4:3) and widescreen (16:9 and 16:10) aspect ratios
Automatically detects the connected displays using VESA compliant protocols
Allows connecting up to 3 adapters and up to 6 monitors per system
Operating power consumption: 2.5W
Display modes: Primary, Extended, Mirror
Resolution:
Standard (4:3 & 5:4):
1600x1200, 1440x900, 1400x1050, 1280x1024, 1280x960, 1152x864, 1024x768, 800x600, 640x480
Widescreen (16:9 & 16:10):
2048x1152, 1920x1200, 1920x1080, 1680x1050, 1600x900, 1366x768, 1280x800, 1280x768, 1280x720
Interfaces/Ports:
1x 9-pin, Type B, USB 3.0, Female, Input
1x 29-Pin, DVI-I, Female, Output
1x 19-Pin, HDMI, Femal...
Specifications: USB-C to DVI cable connects your DVI display to the USB-C or Thunderbolt 3 port on your laptop, MacBook or Chromebook.
Transmits video signals from sources supporting USB DisplayPort Alt Mode
Delivers HD picture quality at resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Supports USB 3.1 Gen 1 speeds up to 5 Gbps to ensure fast data transfers
Reversible USB-C plug connects in either direction for immediate no-fuss use
Easy installation with plug-and-play operation-no software required
Connector:
Side A - Connector 1: USB-C (MALE)
Side B - Connector 1: DVI-D DUAL-LINK (FEMALE) (WIRED TO DVI-D SINGLE-LINK)
Specifications: System Requirements:
Computer with USB-C port that supports USB DisplayPort Alternate Mode
DisplayPort, Mini DisplayPort, VGA, DVI or HDMI external display
Ethernet network
Thunderbolt 3: Yes
Package Contents: U442-DOCK1 USB 3.1 Gen 1 USB-C Docking Station
Owner’s manual
Specifications: Compatible Devices for USB 3.1 Type-C with DP Alt Mode or Thunderbolt 3 (not a full list)
PC:
MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
Dell XSP 15/13
ASUS T303ua/ ZenBook 3
Lenovo YOGA900/910/920 / Lenovo ThinkPad X1 Carbon 5th
Chromebook Pixel 2
HP EliteBook Folio G1/ Spectre 13 X360
Huawei Matebook
And more...
Smartphones:
Huawei Mate 10
Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
Microsoft Lumia 950 / LG G5 / V20 / V30
And more...
Specifications: Supports USB DisplayPort Alternate Mode for Transmitting Video
Reversible USB-C plug connects your device to an existing DVI display, saving you the time, money and effort of additional adapters and cables
Extend video to a second monitor, duplicate the same video on both monitors, or make the second monitor your primary display
Ideal for multitasking, viewing spreadsheet data, editing documents, giving presentations, watching movies and playing video games
Plug and play with no external power supply or drivers required
Compatible with USB-C devices that support USB DisplayPort Alternate Mode
Vibrant, Superior Video Quality
Supports HD video resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Supports USB 3.1 Gen 1 data transfer rates up to 5 Gbps
Supports DVI digital transfer rates of 6.75 Gbp...
Specifications: USB C to DVI Cable enables you to connect a USB-C computer or phone to an DVI-equipped monitor or projector. It is perfect for you to enjoy big screen and efficient life. Audio is not supported over DVI and must be transmitted separately USB-C DP ALT mode source is requested Supports resolution up to 1080 P@60Hz,but we recommend you to make sure your monitor/tv could supply corresponding output. Suport Mirror & Extend Dual Mode Thunderbolt 3 computer host compatible Plug and play, no driver is needed Compatible Devices(not a full list): New iPad Pro Mac Mini MacBook Air 2018 iMac 2017 / iMac 2017 Pro*MacBook Pro 2017 / 2016 (13 &15 inch) MacBook 2016 / 2015 (12 inch) Surface Book 2 HP Spectre X360 Lenovo Yoga 910 HP EliteBook Folio G1 Google Chromebook Pixel DELL XPS 13 Acer Aspire Switch 12S / R13 / V...
Specifications: Supported Resolutions:
1024 x 768
1280 x 720 (High-definition 720p)
1920 x 1080 (High-definition 1080p)
1920 x 1200
2560 x 1440
2560 x 1600
Specifications: 4K Support: Yes
Audio: Yes
Bus Type: USB-C
Chipset ID: VLI - VL812 (USB 3.0 Hub), VLI - VL100 (USB Power Delivery), PS - PS171 (DVI), Realtek - RTL8153 (LAN)
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab; USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0); 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 1920 x 1200 - 60 Hz (DVI)
Maximum Power Delivery Support: 60W
Output Signal: DVI-D (DVI Digital)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type(s): 1 x USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8.1, 10 / Mac OS 10.11 to 10.12 / Chrome OS
Note:
Not all...
Specifications: USB 3.1 Type-C to DVI adapter for connecting a USB-C enabled smartphone, tablet or computer to an DVI-D or DVI-I-equipped monitor or display Compatible with digital DVI-enabled TVs/Monitors/Projectors for video transfer This USB-C to DVI adapter Only Compatible with device with DisplayPort Alt Mode, Windows computers may need updated USB-C or Thunderbolt 3 drivers from the manufacturer. Video resolution up to 1920x1080p@60Hz for compatibility with most displays, monitors and projectors compatible with the following PC, Laptop: iMac 2017 / iMac Pro 2017 MacBook Pro 2017 & 2016 MacBook 2016 & 2015 New Chromebook Pixel Dell XPS 15 & 13 & 12 Yoga 920 Yoga 910, For Yoga 910 users, please ONLY plug the adapter into the White USB-C female port. Yoga 900(Yoga 4 Pro) HP Spectre x360 13 & 15 inch Asus Zen AIO All in One PC Surface Book 2 More...
