Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI / DVI-D / VGA / Mini-DisplayPort
Chipset ID:
Parade - PS176
VIA/VLI - VL102
ITE -IT6516
Audio Specifications: HDMI or mDP output: 7.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz
Maximum Digital Resolutions:
4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz (HDMI)
4096 X 2160 @ 60Hz (mDP)
Supported Resolutions:
Maximum HDMI output: 4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz
Maximum mDP output: 4096 X 2160 @ 60Hz
Maximum DVI and VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0 / DisplayPort 1.2
Wide Screen Supported: Yes
Note: On...
Specifications: Audio Specifications: HDMI and mDP output - 7.1 surround sound
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 x 2160
Supported Resolutions:
HDMI and mDP output: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720
DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported
Humidity: 40%-50%RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -10°C to 80°C (14°F to 176°F)
Specifications: 4K Support: Yes
Audio: Yes
Bus Type: USB-C
Chipset ID: VLI - VL812 (USB 3.0 Hub), VLI - VL100 (USB Power Delivery), PS - PS171 (DVI), Realtek - RTL8153 (LAN)
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab; USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0); 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 1920 x 1200 - 60 Hz (DVI)
Maximum Power Delivery Support: 60W
Output Signal: DVI-D (DVI Digital)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type(s): 1 x USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8.1, 10 / Mac OS 10.11 to 10.12 / Chrome OS
Note:
Not all...
