Features: - Two video stream groups for dual display, each group only supports one to use simultaneously.
- Compatible with TBT4/3 and other USB-C Alt Mode ports on Mac or Windows computer.
- Supports mirror and extend modes.
- Boasts excellent heat dissipation capabilities and occupies minimal space, making it convenient to carry around.
Package Contents: 1x USB 3.0 to DP/HDMI Dual Display Adapter(cable length: 90mm/3.5in), 1x CD-Shaped Card for Driver Download Links, 1x Quick Start Guide
Specifications: Audio: Yes
Chipset ID: MCT Trigger
Memory: 64MB DDRII SDRAM
Output Signal: HDMI
Ports: 2
Audio Specifications: 2-channel stereo
Maximum Digital Resolutions: 4K x 2K @ 30 Hz
Supported Resolutions
Output 1: 3840 x 2160, 2048 x 1152, 1920 x 1200, 1920 x 1080, 1680 x 1050, 1366 x 768, 1280 x 800, 1280 x 768, 1280 x 720, 1600 x 1200, 1400 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 640 x 480
Output 2: 2048 x 1152, 1920 x 1080, 1680 x 1050, 1366 x 768, 1280 x 800, 1280 x 768, 1280 x 720, 1600 x 1200, 1400 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 640 x 480
**All resolutions support 16 and 32 bit color
Wide Screen Supported: Yes
Connector A: 1 x USB Type-A (9 pin) USB 3.0 Male Input
Microsoft WHQL Certified: Yes
OS Compatibility: Windows 10 (32/64), Windows 8 / 8.1 (32/64), Windows 7 (32/64)
Note: T...
Specifications: Chipset ID: MCT - Trigger 1+
Memory: 16MB SDRAM
USB Pass-Through: No
General Specifications: This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Supported Resolutions: Standard (1600 x 1200, 1400 x 1050, 1280 x 1024, 1280 x 960, 1152 x 864, 1024 x 768, 800 x 600) / Widescreen (1680 x 1050, 1440 x 900, 1280 x 800, 1280 x 768, 1152 x 864, 800 x 600)
Connector A: 1 x USB Type-A (4 pin) USB 2.0 Male Input
OS Compatibility: Windows 10 (32/64) / Windows 8 / 8.1 (32/64) / Windows 7(32/64) / Windows Vista (32/64) / Windows XP (32/64)
System and Cable Requirements: One available USB 2.0 port
Specifications: Interface: 1 x USB 3.0 port, 1 x HDMI port Compatible System: Windows 7/8/10/XP operation system Max Resolution: 1920x1080 Resotuion supports:1920x1080,1800x1200,1880x1050,1440x1050,1400x1050,1380x768,1280x1024 etc. Video Function: Primary, Extended, Mirror
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID: Genesys Logic - GL3523 (USB Hub), Realtek - RTL8153 (LAN), Parade Technologies - PS176 (HDMI)
Displays Supported: 1
Fast-Charge Port(s): No
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type: 1 - USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8, 8.1, 10 / Mac OS 10.10 to 10.12 / Chrome OS
Note:
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your laptop USB-C port supports DP alt mode.
A 4K-capable display is required to achieve 4K x 2...
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID:
Genesys Logic - GL3523
Realtek - RTL8153
Eton Technology - EJ899T
Parade Technologies - PS176
ITE -IT6516
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Analog Resolutions: 1920 x 1200p @ 60Hz (VGA)
Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p @ 30Hz (HDMI)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
macOS 10.11 to 10.14
Chrome OS
Specifications: 4K Support: Yes
Bus Type: USB-C
Displays Supported: 1
Fast-Charge Port(s): No
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0) / 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 3840 x 2160p (HDMI)
Type and Rate USB: 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility: Windows 7, 8, 8.1, 10 / Mac OS 10.9 to 10.12 / Chrome OS
Power Source: USB-Powered
Output Connector: 1 x USB Type-C (24 pin) USB 3.0 Male
1 x HDMI (19 pin) Female
1 x RJ-45 Female
2 x USB Type-A (9 pin) USB 3.0 Female
1 x USB Type-C (24 pin) USB 3.0 Female
Specifications: 4K Support: Yes
Audio: Yes
Bus Type: USB-C
Chipset ID: VLI - VL812 (USB 3.0 Hub), VLI - VL100 (USB Power Delivery), PS - PS171 (DVI), Realtek - RTL8153 (LAN)
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab; USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0); 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 1920 x 1200 - 60 Hz (DVI)
Maximum Power Delivery Support: 60W
Output Signal: DVI-D (DVI Digital)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type(s): 1 x USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8.1, 10 / Mac OS 10.11 to 10.12 / Chrome OS
Note:
Not all...
Specifications: 4K Support: Yes
Bus Type: USB-C
Displays Supported: 1
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Maximum Power Delivery Support: 60 W
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
Mac OS 10.9 to 10.12
Chrome OS
Specifications: Ports: HDMI, USB Type A 3.0, Gigabit Ethernet & USB-C PD charging ports
Operating System Requirements: Windows 7 / 8 / 8.1 / 10, Mac OS X 10.7
Specifications: Voltage: 5VDC
Color Depth: 32-bit color
Video Resolution: up to 2048x1152 @ 32-bit color
Power Supply: Bus powered- no power supply needed
Operating System Support: Windows® 7, Windows® 8, Windows® 8.1, Mac OS X 10.6+
Power On: Green
