Specifications: Output Signal: VGA
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: PC resolutions up to 1920 x 1200 @ 60 Hz
Connector Type(s): 1 x USB Micro-B (5 pin) Female
Power Source: USB-Powered
Humidity: 40 - 85%RH
Operating Temperature: 0 to 60 degree C (32 to 140 degree F)
Storage Temperature: -10 to 70 degree C (14 to 158 degree F)
Specifications: Resolution: 3840 x 2160 at 30Hz (Dual Display)
Resolution: 3840 x 2160 at 60Hz (Single Display)
Output: Requires 5V, 2A external power over Micro-B USB port
DisplayPort 1.2a compliant
Link Rate: HBR2/HBR/RBR
Bandwidth: 5.4Gbps max.
Support SST and MST (when both host and monitor support)
Support 7.1 sound channel; max. sampling size 192KHz
Rating: Temp 80°C, Voltage 30V
Conductor Resistance: At 20°C max 30AWG: 376.95 O/KM
Insulation Resistance: 10M -KM min at 20°C DC 500V (EIA-364-21)
Dielectric Strength: AC 500V/1 minute no breakdown (EIA-364-20)
Impedance: Pairs (differential mode) 100±50HMS
Attenuation (max.): 5.02dB@100~450MHz; 7.695dB@1GHz; 12.595dB@2GHz; 17.495dB@3GHz; 22.395dB@4GHz; 27.295dB@5GHz; 32.195dB@6GHz; 37.095dB@7GHz
Return...
Specifications: Active or Passive Adapter: Active
AV Input: HDMI
AV Output: Audio RCA, Composite
Industry Standards: Standard HDMI, DVI 1.0
Audio Specifications:
Input - LPCM 2Ch, 48kHz
Output - Stereo L/R
Supported Resolutions:
Input
TV - 1080p, 720p, 576p, 480p @ 60Hz
PC - 1920x1080, 1280x800, 1280x768, 1224x768, 800x600, 640x480 @ 60Hz
Output: 480i, 576p
Input Current: 0.4 A
Input Voltage: 100 ~ 240 AC
Output Current: 2000 mA
Output Voltage: 5 DC
Plug Type: M
Power Source: AC Adapter Included
Specifications: 192khz DAC optical digital to analog adapter converter
Inputs: Coaxial, Toslink & USB
Optical/Coaxial input audio format: PCM / LPCM
Optical/Coaxial input sampling rate: 32, 44.1, 48, 96 and 192KHz
Headphone amplifying power: 125mW x2 @ 32O
Suggest headphone esistance range: 32-600O
It can convert optical, USB(For PC), and Coaxial digital audio signals into stereo analog audio signals that are connected to the amplifier. Help users solve the problem of connecting different audio interfaces to analog amplifiers.
Package Contents: 1 X Digital to analog audio converter
1 X USB power cable
1 X IR Remote Control
1 X User Manual
Specifications: Performance Grade: Good
Resolution: Supports PC resolutions up to 1920x1200(WUXGA-R), 60Hz, 8bpc: 154MHz;1920x1080P, 60Hz, 10bpc: 144MHz
Versions Supported: DisplayPort 1.1 input and VGA output
Power requirements: Powered from DisplayPort source
Construction: The DP to VGA adapter uses an integrated chip to provide an active digital to analog conversion
Weight Lbs: 0.2
RoHS Compliant: Yes
Specifications: Quad-shielded cable with PVC jacket for maximum audio/video performance & prevention of signal loss
Display modes:
PC VGA, SVGA, XGA, SXGA, & UXGA display modes
HDTV: 480i, 576i, 480p, 576p, 1080i & 1080p
Supports multi-channel digital audio (system's DisplayPort must support audio)
AC to DC level trigger - requires dual-mode Display Port source
RoHS compliant
