Mobile Micro Usb Portable Smart Card Reader DCR32

Mobile Micro Usb Portable Smart Card Reader DCR32

Specification

Host Interface

USB 2.0 CCID1 (also compliant with USB 1.1)

Transmission Speed

12 Mbps (USB 2.0 full speed)

Power Supply

Bus powered

Smart Card Interface

Standards

ISO 7816 & EMV2 2000 Level 1

Protocols

T=0, T=1,

2-wire: SLE 4432/42 (S=10),

3-wire: SLE 4418/28 (S=9),

I2C (S=8)

AT88sc1608/ 153, AT24c128/ 256

ST: M14C16, M14C04

Card Size

ID-1 (full-size)

Smart Card Interface Speed

420 Kbps (when supported by card)

Smart Card clock frequency

Up to 5 MHZ

Supported card types

5V, 3V and 1.8V Smart Cards

ISO 7816 Class A, AB and C

Iternal Memory

1MB

Power to Smart Card

60 mA

Other Features

Status Indicator

YES

Options

Customer specific logo or label

On request

Customer specific colors

On request

PC/SC Driver Support

Windows® 98 / ME, 200 / XP (32bit), 2003 Server

Windows® CE 5.0 (depending on hardware)

Windows® Vista (32bit / 64bit)

Windows® 7/ 8/10/ Mac OS

Linux® (need Micro USB to USB Adapter)

Hardware Specifications

Operating temperature

0º-55ºC / 32-131ºF

Operating humidity

10-90% rH

Composition

ABS

Connector cable

100 cm / 70.9"

Durability

100.000 insertions

Meantime between failure (MTBF)

500.000 hours

Packing Detail

Carton Dimension

63 * 28 * 20 cm

Carton/pcs

100 pcs /Ctn

N.W.

7 kg

G.W.

8 kg

Certification
