Specifications: Unit Dimension: 15.50 x 69.00 x 133.00mm
Power Input:
Logic: 2.97V to 3.63V, 4.5V to 5.5V
Fan: 11.4V to 12.6V
RGB LED: 4.5V to 5.5V
Cable:
USB: 440mm
SATA Power: 465mm
Thermal sensor: 610mm
Fan extension: 300mm
RGB LED channels: Two 2-pin connector
Max. RGB LED strip per channel: 4
Max. RGB fan per channel:6 through 1 RGB LED hub
Specifications: Material Plastic Shell
Signal input:
Standard addressable RGB 3Pin +5V, D, G*
Motherboard addressable RGB 4pin +5V, D, NP, G*
Signal output: SilverStone custom addressable RGB 3pin +5V, D, G** x 8
Power Input: SATA 15pin
Output limitation (each port): 5V 9A (4.5A+4.5A)***
Included Parts:
8 x Standard addressable RGB 3pin cable
1 x SATA power cable
1 x Input signal cable
Specifications: Unit Dimension: 15.50 x 69.00 x 133.00mm Power Input: Logic: 2.97V to 3.63V, 4.5V to 5.5V Fan: 11.4V to 12.6V RGB LED: 4.5V to 5.5V Cable: USB: 440mm SATA Power: 465mm Thermal sensor: 610mm Fan extension: 300mm RGB LED channels: Two 2-pin connector Max. RGB LED strip per channel: 4 Max. RGB fan per channel:6 through 1 RGB LED hub
Specifications: Dimension: 90mm x 53mm x 14mmWeight (g): 122Masterial: Plastic, PCBControl Method: Cooler Master SoftwareInput Connector: SATA PowerOutput Channel Voltage: 12vOutput Channels: 4 ports (Port 1, 2 for frequency control) Lighting Mode: Static , Breathing, Color Cycle, Stars,Customize , Multilayer, Turn off, Mirage(Frequency control) Included Accessories:4 x 450 mm Extension cable1 x 600 mm Extension cableInterface: USB connectors (9 Pin)
