Specifications: Material: 18 pcs 5050 RGB LED with magnetic strip and adhesive tape
Pin definition: +12V, G, R, B
Included Parts:
RGB LED strip x 2
Y cable x 2
Length: 300mm
Wattage: 1.44W (12V, 0.12A)
Tandem limits: 5 pcs on each line
Weight: 30g
Specifications: Material: Plastic outer shell
Output limitation (each port):
Addressable RGB port: 72 LED per port, total 5V, 5A
Fan Port : total 12V, 3A
Color Selection: Support 2812 IC Addressable RGB LED
Signal output:
Standard Addressable RGB 3pin + 4-1pin x 6*
Fan 4pin port x 4 (compatible with 3pin)
Included Parts:
6 x Standard Addressable RGB cable
1 x Peripheral power Y cable
1 x RF remote
1 x Thermal sensor cable
1 x Power switch cable
Specifications: Color: Blue
Material: Plastic strip with 15 LED(3.6W) and adhesive tape
Operating system support: 12V
Connectors:
Peripheral to LED 4pin connector x 1
4pin daisy chain connector x 1
Length: 300mm
Weight: 22g
Specifications: Color: Red
Material: Plastic strip with 15 LED(3.6W) and adhesive tape
Operating system support: 12V
Connectors:
Peripheral to LED 4pin connector x 1
4pin daisy chain connector x 1
Length: 300mm
Weight: 22g
Specifications: Color: White
Material: Plastic strip with 15 LED(3.6W) and adhesive tape
Operating system support: 12V
Connectors:
Peripheral to LED 4pin connector x 1
4pin daisy chain connector x 1
Length: 300mm
Weight: 22g
Specifications: Type: 3 Strip RGB LED Control Pack
Form Factor: Slim Profile
Voltage: 12V
LED Strips: (3) RGB Magnetic LED Strip
Mounting: 6 Neodymium Magnets + 3M Adhesive
LED Lights/Strip: 12
Fans Channels: 5
LED Modes: Flash Mode (Blue > Green > Red > White > Orange > Yellow > Purple) and 256 Color Fade Mode
Buttons:
Customize Button (256 Color Mode)
Mode Button (Color Select/Flash)
Brightness Button (Adjust Brightness Levels / Power On/Off)
LED Strip Chaining Capable: Yes
Power Connector: (1) 4-pin Fan Header
Weight: 145g
Color: Black
Dimensions: 80 x 60 x 20 mm
Specifications: Material 12 pcs addressable RGB LED with magnetic strip and adhesive tape
Pin definition:
+5V, D, G*
+5V, D, NP, G*
Included Parts:
2 x Addressable RGB LED strip
1 x Motherboard connect cable**
1 x Splitter cable
Length: 300mm
Wattage: 3W (5V, 0.6A)
Tandem limits: Depend on controller
Remark:
* Please check the control box and motherboard pin header that you want to connect are the same as LS03’s pin definition.
** Included Motherboard connect cable supports SilverStone’s addressable RGB 3pin connectors and other market standard addressable RGB 3pin (three pin in four pin housing) connectors.
