Specifications: Meets ANSI/EIA/TIA 568-B.2-1 and ISO/IEC 11801 Standards
New version 110D IDC type terminal blocks (use 110 or Krone type tool)
Color-coded labeling for T568A and T568B wiring schemes
180° angle type (horizontal)
1000Base-T Copper Gigabit Ethernet ready
Compatible with Cat. 3, 4, 5, 5e, and 6 cabling
Works perfectly with TC-PDT Punch Down Tool
Operating temperature: -40° ~ 80° C (-40° ~ 176° F)
UL E157358 listed
Specifications: Installed whole system maximum rack depth (inches) 5.5
Installed whole system maximum rack depth (cm) 13.97
Rack Height 4U
Shipping Dimensions (HWD/in) 6.5 x 20.5 x 7.5
Shipping Dimensions (HWD/cm) 16.51 x 52.07 x 19.05
Shipping weight (lbs) 5.7
Shipping weight (kg) 2.59
Unit Dimensions (HWD/in) 7 x 19 x 6
Unit Dimensions (HWD/cm) 17.78 x 48.26 x 15.24
Unit weight (lbs) 5
Unit weight (kg) 2.27
Color Black
Weight Capacity - Stationary (lbs) 35
Weight Capacity - Stationary (kg) 15.9
Specifications: U Height: 1U
Frame Type: Open Frame
Wallmountable: Yes
Front Door Type: Open
Fan(s): No
Weight Capacity: 17.7 lb [8 kg]
External Width: 19 in [483 mm]
External Height : 1.7 in [44 mm]
External Depth: 6 in [152 mm]
Included in Package:
1 - 1U Hinged 19" Wallmount Bracket
4 - Screws
