Specification: Hardware
Audio: No
Industry Standards: DDC compatible - all other monitors must be able to support the highest video resolution of the DDC-type monitor connected to Video Out 1
Ports: 2
Regulatory Approvals: FCC Part 15 Class A, CE Mark
Performance
General Specifications: Male to Female VGA extension cable required (MXT101HQ)
Maximum Cable Length: 213.2 ft. [65m]
MTBF: 1,588,136 Hours
Environmental
Humidity: 0~80% RH Non-condensing
Operating Temperature: 5 degree C to 40 degree C (41 degree F to 104 degree F)
Resolution Support: Maximum Analog Resolutions: 2048x1536 @ 80Hz
Distance: Max Distance: 70m (230 ft.)
Maximum 1080p Distance: 70m (230 ft.)
Maximum 4K Distance: 35m (115 ft.)
Resolution Support: 4K x 2K (Ultra HD) @ 30 Hz
2560 x 1600 @ 60 Hz
1920 x 1200
1920 x 1080 (1080p)
1280 x 720 (720p)
Power Consumption: 64.8W
Power Supply: Center Tip Polarity: Positive
Input Current: 1.5A
Input Voltage: 100 ~ 240 AC
Output Current: 2.7A
Output Voltage: 24 DC
Plug Type: 4-pin DIN
Power Source: AC Adapter Included
