Specification: Connectors
Video In: 1 x DVI-D Female (White)
Audio In: 1 x Mini Stereo Jack (Green)
RS-232: 1 x DB 9 Female (Black)
Video Out: 2 x DVI-D Female (White)
Audio Out: 2 x Mini Stereo Jacks (Green)
Power: 1 x DC Jack
LEDs
Link -1 (Green)
Power - 1 (Green + Orange)
Resolution: Up to 2560 x 1600
Power Consumption: DC5.3V, 3.1W
Signal Range: 5 m (15 ft)
Environment
Operating Temp: 0-50 degree C
Storage Temp: -20-60 degree C
Humidity: 0-80% RH, Non-condensing
Dimension: 8.27" x 3.46" x 2.19"
Weight: 1.5 lbs.
Feature: Displays DVI audio/video to multiple DVI-compatible monitors or projectors
Superior video quality - up to 2560 x 1600 @ 60Hz and 1080p
Cascadable to 3 levels - provides up to 8 video signals
Audio enabled
Features RS-232 serial port for command controls
RS-232 Chain Contro...
Specification: Hardware
Audio: No
Industry Standards: DDC compatible - all other monitors must be able to support the highest video resolution of the DDC-type monitor connected to Video Out 1
Ports: 2
Regulatory Approvals: FCC Part 15 Class A, CE Mark
Performance
General Specifications: Male to Female VGA extension cable required (MXT101HQ)
Maximum Cable Length: 213.2 ft. [65m]
MTBF: 1,588,136 Hours
Environmental
Humidity: 0~80% RH Non-condensing
Operating Temperature: 5 degree C to 40 degree C (41 degree F to 104 degree F)
Resolution Support: Maximum Analog Resolutions: 2048x1536 @ 80Hz
