Specifications: Supported APIs:
Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
Linux
- V4L2
- ALSA
Supported Software
VLC
VirtualDub
OBS
xSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software
Input Features
Support for input video resolutions up to 2048x2160 pixels
HDMI Specific Features:
225MHz HDMI receiver
Adaptive HDMI equalizer support for cables lengths up to 30M
Support for customized EDID
Support for extraction of AVI/Audio/SPD/MS/VS/ACP/IRSC1/ISRC2/ Gamut InfoFrames
Full colorimetry support
Support for 8/10/12-bit color depths
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for up to 8-channel IEC60958/IEC61937 audio streams
Support for extraction of audio formation information & channel status data
Supp...
Specifications: Resolution:
Up to 4K@30Hz
Ethernet:
10/100/ 1000-BASE-T RJ-45 LAN
Wireless:
Miracast and Local Wi-Fi Mode: 802.11ac dual-band 3x3 MIMO
Network Bridge: 802.11ac dual-band 2x2 MIMO
Authentication
WPA-PSK (TKIP)
Protocol:
WPA2-PSK (AES)
PEAP-MSCHAP V2
EAP-TLS
Content Protection:
HDCP 2.x
Power:
Input: 12VDC, 3A
Consumption: 8.4W (typical), 36W (peak)
Dimensions:
8.66 x 5.66 x 1.47 inch (220 x 144 x 37.5 mm)
Operating temperature:
0º - 40º C (32º - 104º F)
Storage temperature:
-20º - 85º C (-4º - 185º F)
Operating humidity:
20 - 80% non-condensing
Storage humidity:
10 - 90% non-condensing
Language support:
English
Simplified Chinese
Traditional Chinese
Japanese
French
German
Dutch
Korean
Spanish
Italian
Russian
Regulatory and compliance:
Approved: FCC and UL
Pending: CE, RoHS and C-Tick
Interface: 1 x HDMI Input
1 x HDMI Output
2 x USB 2....
Specifications: Video Resolution: 480p, 720p, 1080i and 1080p with 3D support
Video Streaming: <1ms Latency
Frequency: 4.9 ~ 5.9 GHz (Includes Non-DFS and DFS Frequency Bands)
Range: Maximum video transmission range is 30 ft. (10m)
LEDs
Power On: Transmitter: 1 x Blue LED; Receiver: 1 x LED (two-tone: green & red)
Power
Amps: 1A (Transmitter) and 1.5A (Receiver)
Voltage: 5V DC Mini USB (Transmitter and Receiver)
1 x Mini USB Power Jack (Transmitter and Receiver)
Operating Temperature: 0 ~ 40°C
Unit Dimensions: 0.75" x 1.12" x 3.12"
Weight: 1.55 lbs.
Interface: HDMI
Audio: Audio Output:
Digital 6Mbps, 2 to 8 channels 16 ~ 24 bits/sec by I2S and S/P DIF bus over WHDI transmission (Dolby Digtial & DTS)
