Type: WorkFit C-Mod, Single Display Sit-Stand Workstation
Specifications: LCD Size: = 22"
Capacity: 5–18 lbs/2.3–8.1 kg
Lift: 25"/63 cm
Tilt: 25°
Rotation: 360° P/L
VESA: MIS-D
Includes cart, LCD pivot, integrated worksurface, keyboard tray with left/right mouse tray, wrist rest, mouse holder, cable storage box, CPU holder, four dual casters (two locking)
Lift Range: LCD/keyboard/worksurface adjusts 20" (51 cm) in tandem; LCD adjusts 5" (13 cm) independently; maximum LCD height adjustment = 25" (63 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Constant Force (CF) lift-and-pivot motion technology
CPUs attach safely to rear of cart with CPU Holder. Accommodates CPUs from 12"H x 3"D to 18"H x 8.5"D (30 x 8 cm to 46 x 22 cm)
CPU Holder capacity = 40 lbs (18 kg)
Ergonomic negative-t...
Specifications: Wallmountable: No
Tools Included: Yes
Articulating: Yes
# of Displays Supported: 1
Mounting Options: Desk Clamp
VESA Hole Pattern(s):
75 x 75 mm
100 x 100 mm
Mounting Surface Thickness: Desk Clamp: Maximum Table Thickness of 85mm (3.3 in)
Maximum Arm Extension: 22.4 in
Laptop Arm Extension: 22.4 in
Display Tilt: -85° / +90°
Laptop Tray Tilt: 90° tilt from horizontal to vertical
Swivel / Pivot: -180° / +180°
Display Rotation: 360°
Specifications: Weight Capacity: 6–16 lbs (2.7–7.2 kg) for display; total stand capacity = 37 lbs (16.7 kg) for combined weight of display, CPU, keyboard and mouse
Motion may be restricted when using 22"–24" monitors in portrait mode
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Five-inch (13 cm) height adjustment ergonomically accommodates average range of users
Meets tip test requirements of UL Specification 1678 + Removal of lock screw allows portrait to landscape rotation (90°)
Compatible with most 15"–24" displays, and most small or ultra small form factor CPUs.
Maximum CPU size = 15"W x 14"H x 4.5"D (38 x 35.6 x 11.4 cm); minimum CPU size = 7"W x 7"H x 2"D (18 x 18 x 5.1 cm). Provided rubber spacer must be used to accommodate CPU depths of less than 3" (7.6 cm)
Moun...
Specifications: Description: Tall-User Kit for WorkFit Dual
Includes two (2) single monitor pivots, two (2) riser brackets, installation hardware
* Maximum outside width of display is 21.25" (54 cm) when displays are 2" (5 cm) thick. This is typically the horizontal dimension of a 22" diagonal screen-size monitor. Actual allowable width of displays will vary slightly depending on display thickness
** Weight Capacity: 6 - 14 lbs. (2.7 - 6.3kg) per display, 12 - 28 lbs. (5.5 - 12.7kg) combined
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Specifications: Display size is dependent on overall configuration of the DS100 Stand; observe balance requirements to prevent tipping
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Attaches to DS100 Pole only; cannot attach to DS100 Crossbar
Specifications: Device Support: Flat Panel Display
Load Capacity: 6-18 lb Maximum for Display
5 lb Maximum for Keyboard, mouse and barcode scanner
Maximum Screen Size Support: 24"
Rotation: 30° - Tilt
Pan: 360°
Rotation: 90°
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Integrated mouse and barcode scanner holder provide easy access
Integrated fold-down keyboard tray with right/left mouse tray (includes built-in mouse pad surface)
Negative-tilt keyboard tray adjustable 0 to -10 degrees
Durable, easy-to-clean exterior composed of aluminum, high-grade plastic and powder-coated painted steel
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud. Separately ordered Wall Track or Wall Plate accessory is recommended to strengthen...
Specifications: LCD Size: < 24"
Wt. Capacity: < 25 lbs, 11.3 kg
Tilt: 180°
Rotation: 360° P/L
VESA: MIS-D
Description: Neo-Flex Dual Monitor Wall Mount
Includes two (2) 100 Series Single Pivots, 26" Wall Track, two (2) Track Mount Bracket Kits
Mounting Standards: VESA FDMI, MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
