Specifications: Weight Capacity: display = 6-18 lbs (2.7-8.2 kg), worksurface = 10 lbs (4.5 kg), keyboard, mouse and barcode scanner = 4 lbs (1.8 kg), CPU = 50 lbs (22.7 kg)
Lift Range: LCD and keyboard adjusts 20" (51 cm) in tandem with single-motion, LCD adjusts 5" (13 cm) independently, maximum LCD height adjustment = 25" (64 cm)
Monitor up/down tilt: +25 degree /-5 degree
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Worksurface: 22.75"W x 10.6"D (57.8 x 26.9 cm)
Keyboard tray: 18.6"W x 9"D (47.2 x 22.8 cm)
Back-tilt keyboard tray adjustable: 0 degree to -10 degree
CPU Size Range: 1-3/8" to 3-3/4" (35 to 95 mm) wide, accommodates most small form factor and ultra small form factor CPUs
Product Weight: 39.6 lbs (18 kg)
Specifications: Description: WorkFit-C Sit-Stand Workstation for Two LCD Monitors, Dual, with Mobile Cart Base (black/grey)
Includes cart, two (2) LCD mounts, crossbar, integrated worksurface, large stowable keyboard tray, cable storage box, CPU holder, four dual casters (two locking), hand-brake system
**** Maximum outside width of each display = 21.25" (54 cm)
* Weight Capacity: Maximum load on height-adjustment assembly = 32.5 lbs (14.7 kg). Includes weight of displays and keyboard in addition to contents on Worksurface and in Cable Storage Box. LCD mount capacity = 6-14 lbs (2.7-6.3 kg) each, 12-28 lbs (5.5-12.7 kg) total
*** Lift Range: LCDs/keyboard/worksurface adjust 20" (51 cm) in tandem; LCDs adjust 5" (13 cm) independently; maximum LCD height adjustment = 25" (63 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 1...
Specifications: Weight Capacity: 23 lbs
LCD Size: 24"
Tilt: 180º
Pan: 180º
Rotation: 360º
Monitor depth greater than 3" (7.5 cm) may diminish capacity
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud. To increase support, a separately-ordered Wall Plate or Wall Track accessory is recommended
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Shipping Weight: 3 lbs (1.4 kg)
Specifications: Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
LCD Size: 30"
Capacity: 31 lbs
Rotation: 360° P/L
Attaches to Crossbar and Crossbar Extenders
Cannot be used as the Center Display Bracket when three displays are attached to Crossbar
Install displays with 4°-angle off-set : position them upward, inward or downward for optimized viewing conditions
Specifications: Mounting Options: Attach through worksurface hole 3/8" to 3" (10 to 76 mm) wide and up to 3-1/4" (82 mm) thick. For maximum support, screw should be centered through hole
Works with DS100 Quad-Monitor Desk Stand
Specifications: Weight Capacity: 6–16 lbs (2.7–7.2 kg) for display; total stand capacity = 37 lbs (16.7 kg) for combined weight of display, CPU, keyboard and mouse
Motion may be restricted when using 22"–24" monitors in portrait mode
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Five-inch (13 cm) height adjustment ergonomically accommodates average range of users
Meets tip test requirements of UL Specification 1678 + Removal of lock screw allows portrait to landscape rotation (90°)
Compatible with most 15"–24" displays, and most small or ultra small form factor CPUs.
Maximum CPU size = 15"W x 14"H x 4.5"D (38 x 35.6 x 11.4 cm); minimum CPU size = 7"W x 7"H x 2"D (18 x 18 x 5.1 cm). Provided rubber spacer must be used to accommodate CPU depths of less than 3" (7.6 cm)
Moun...
Specifications: Max Weight per mount (lbs): 26.5
Quick release Mounting Head: Yes
Mounting Hole Pattern (mm):
- 75 x 75; 100 x 100
- Require 200 x 100 Add AC-AP-2010 adaptor plate to your order
Screen rotation (portrait/landscape): 360°
Rotation around pole: 360° OR FIXED
Tilt/pan adjustment: Ball joint mechanism allows 20 degrees display adjustment in any direction from the vertical plane
Display pan adjustment: 90 degrees left and right, total of 180 degrees
Pole height (inches): 29.5
Cable management: Integrated
Mounting options: Desk clamp and bolt through
Pole diameter(inches): 1.6
Display Compatibility:
- Spacedec Donut Pole is compatible with most Flat Panel Displays between 12" (30cm) and 24" (61cm) that feature either 75mm x 75mm (3 x 3") or 100mm x 100mm (4 x 4") VESA mounting hole patterns
Mount...
Specifications: Description: Worksurface for WorkFit-S Sit-Stand Workstations (black)
Includes worksurface, mounting brackets with integrated handle, and mounting hardware
Worksurface Dimensions: 0.25" H x 23" W x 15 "D (6 x 585 x 380 mm)
Cannot be added to system where Tablet/Document Holder accessory 97-558-200 is installed
Installation of the worksurface will not impact normal 20" (51 cm) range of sit-stand height adjustment, but may impact the relative vertical adjustment of larger displays when in portrait orientation
When this accessory is added to the WorkFit-S, total weight capacity of the workstation is reduced by 6 lbs (2.7 kg)
Type: WorkFit C-Mod, Single Display Sit-Stand Workstation
Specifications: LCD Size: = 22"
Capacity: 5–18 lbs/2.3–8.1 kg
Lift: 25"/63 cm
Tilt: 25°
Rotation: 360° P/L
VESA: MIS-D
Includes cart, LCD pivot, integrated worksurface, keyboard tray with left/right mouse tray, wrist rest, mouse holder, cable storage box, CPU holder, four dual casters (two locking)
Lift Range: LCD/keyboard/worksurface adjusts 20" (51 cm) in tandem; LCD adjusts 5" (13 cm) independently; maximum LCD height adjustment = 25" (63 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Constant Force (CF) lift-and-pivot motion technology
CPUs attach safely to rear of cart with CPU Holder. Accommodates CPUs from 12"H x 3"D to 18"H x 8.5"D (30 x 8 cm to 46 x 22 cm)
CPU Holder capacity = 40 lbs (18 kg)
Ergonomic negative-t...
Specifications: Weight Capacity:
Display = 6 - 18 lbs. (2.7 - 8.2kg) or up to 25 lbs (11.4kg) with tilt and lift lock-out features engaged
keyboard, mouse and barcode scanner = 4 lbs (1.8kg)
CPU = 50 lbs (22.7kg)
Lift: 25" (64cm)
Tilt: Up +25 degree/ Down -5 degree
Mounting Pattern: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Pan: 360 degree
Rotation: 360 degree
Keyboard Tray Dimensions: 18.6" x 9" (47.2 x 22.8cm)
CPU Dimension: 1-3/8" to 3-3/4" (35 to 95mm) wide; accommodates most small form factor and ultra small form factor CPUs
Monitor Size: Up to 24"
Specifications: Complies with UL Tip Standards 1667 and 1678
Rugged plastic-composite shelf conveniently attaches to cart at any height
Modular cable channel system is adaptable for various wiring configurations
Add the MMC Camera Shelf Kit to place adjustable camera shelf above the display (ordered separately); shelf is not compatible with the NF MMC LD, 24-190-057, when using the optional small LCD monitor pivot (includes 75 mm and 100 mm mounting holes), which is typically used with 25 lbs (11. 4 kg) to 36 lbs (16.3 kg) displays. As an alternative, the NF WideView cart, 24-189-055, does accommodate this size monitor and a camera shelf
CPUs attach safely to rear of cart with Universal CPU Holder accessory (ordered separately). Compatible with CPU sizes from 12" H x 3" D to 18" H x 8.5" D (300 x 80 mm to 460 x 220 mm)...
Specifications: Includes mouse pad, wrist rest, mouse pouch
+ Larger display sizes may inhibit the keyboard tray folding flat in storage position
Weight Capacity: Listed weight capacity represents total load, including both the monitor and contents of keyboard tray. Maximum monitor weight = 25 lbs (11.3 kg); monitor thickness greater than 3" (7.6 cm) may decrease capacity
Mounting Standards: VESA FDMI MIS-D, 100/75 (hole pattern: 100 x 100 mm & 75 x 75 mm)
Fold-down keyboard tray
Negative-tilt keyboard tray is adjustable 0° to -10°
Integrated cable management system can be configured on either side
Easy-to-clean exterior
Specifications: Includes 10" and 34" Wall Tracks with (2) black track covers, LX Sit-Stand Wall Mount LCD Arm, LX Sit-Stand Keyboard Arm, wrist rest, mouse holder, Medium CPU Holder, two (2) 10" Cable Channels, mounting kits for hollow-wall and wall-stud installation
Quality Tested: 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment
Weight Capacity: display = 7-25 lbs (3.2-11.3 kg); keyboard = 5 lbs (2.2 kg); CPU = 40 lbs (18 kg). Monitor depth may affect weight capacity. Read more
Monitor tilts 70 degrees up and 5 degrees down
Rotation Stop on wall-mount base limits turn of extension-base connection to 180 degrees, preventing extension from contacting wall
Locking connections between arm, extension and base offer increased theft deterrence and prevent potential disconnections caused by j...
