Specifications: Includes worksurface, cable/brick storage compartment, storage hook, 3" (75 mm) casters (2 locking), tablet riser with tilting tablet mount assembly, scanner holder
Choose the level of security that is right for your tablet. This cart ships with three options: Hard-mount your tablet case directly to the VESA mount at the top of the riser if case includes VESA hole pattern; or add the easel bracket to the VESA mount and place your tablet on its surface; add the top grip to the easel bracket to clamp the tablet for extra stability when moving the cart. VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Tablet can be installed in either landscape or portrait mode
When installing tablet using easel bracket, tablet must fit within these dimensions: maximum outside width = 12.25" (...
Specifications: Includes height-adjustment column, desk clamp, LCD pivot, worksurface, large keyboard tray
NOTE: Extra-long cables may be required to span between standing and sitting heights
Weight Capacity: Maximum total load on height-adjustment assembly = 29 lbs (13.2 kg). LCD weight = 16-28 lbs (7.3-12.7 kg), worksurface = 5 lbs (2.3 kg), keyboard tray = 5 lbs (2.3 kg). For proper operation the total weight of components when added together should not exceed 29 lbs (13.2 kg)
Lift Range: LCD and keyboard adjust 18" (46 cm) in tandem; LCD adjusts 4.8" (12.2 cm) independently; maximum LCD height adjustment = 22.8" (58 cm). The worksurface restricts the vertical travel range of the LCD lift pivot; height adjustment of LCD without worksurface is 5" (13 cm)
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern = 100 ...
Specifications: Includes height-adjustment column, desk clamp, crossbar, two (2) LCD pivots, worksurface/keyboard, one (1) USB extension cable, two (2) cable wraps
NOTE: Extra-long cables are required to span between standing and sitting heights
Optimized for desks that are 30"-36" deep (76-91 cm): on desks shorter than 30", worksurface will extend beyond desktop edge; on desks deeper than 36", worksurface will not extend to desktop edge
Worksurface Dimensions: 29.5" x 21.8" (75 x 55.4 cm)
Maximum outside width of display is 24.5" (62 cm) when display is 2" (5 cm) thick. Accommodates most displays with screen-size up to 24" as well as some displays with screens as large as 26". Actual allowable width of displays will vary depending on display thickness
Weight Capacity: Maximum total load on height-adjustment assembly = 25 ...
