Ruckus 901-H510-US00

The ZoneFlex™ H510 is a Wave 2 802.11ac (MU-MIMO-capable) Wi-Fi access point with integrated switch in a wall-plate form factor.

H510 features Ruckus' patented BeamFlex + adaptive antenna technology to deliver high-speed 802.11ac WiFi in a low-profile design that can be discretely installed over a standard electrical junction box. H510 allows a range of wired & wireless services to be delivered in hotel guest rooms student residences and multi-dwelling units with just a single cable pull per room and eliminates the need for additional switches and power supplies.

Equipped with four Ethernet ports for in-room access the ZoneFlex H510 can be used to connect a range of wired network devices such as IPtv set top boxes IP telephones or networked minibars while simultaneously providing dual band 802.11ac wireelss LAN coverage. An IEEE 802.3af-compliant Power-over-Ethernet (PoE) port on the H510 allows devices such as IP telephones to be powered directly from the wall switch. The H510 itself may be powered via standard PoE or a DC power adapter. The H510 can be deployed as a standalone device or centrally managed by SmartZone ZoneDirector or FlexMaster management platforms.
