Type: NC325m PCI Express Quad Port Gigabit Server Adapter
Specifications: Compliance: IEEE 802.3ab, 802.3u, 802.3x, 802.3ad, 802.3p, 802.1Q
Bus type: PCI Express
Data path: Four lanes (x4)
Onboard memory 312 KB (Note: Consisting of a 56K Receive Buffer and a 22K Transmit buffer for each port.)
Transfer rate: 1000Mbps
Ports: Four
Controller: Broadcom 5715S
Power requirements:
Operating voltage : +12V +/- 8%
Maximum: 1.05A @ 12V(DC)
Operating:
Temperature: Meets the external specifications for the BladeSystem enclosure which is 50° to 95°F (10° to 35°C)
Humidity: 10% to 90% non-condensing
Non-operating:
Temperature: -40° to 185°F (-40° to 85°C)
Humidity: 5% to 95% non-condensing
Emissions classifications: Class A
Specifications: RoHS Compliance: Yes
Form Factor: Desktop Enclosure
Host Interface: USB 2.0 and IEEE 1394B
HDD Interface: 3.5" SATA I/II
Hotswap 3.5": 2
LED Display: Green - Power on indicator Blue - Busy (HDD Accessing) indicator
Material: Plastic and Aluminum alloy
OS Support: OS Independent
Package Content:
1 x Enclosure
2 x HDD Tray
1 x USB 2.0 Cable
1 x FireWire 800 Cable
1 x Power Adapter w/ Power Cord
8 x Hard Disk Drive mounting screw
2 x Key for HDD tray
Power Supply: External Power Adapter (AC input: 100-240V ~ 1.0A 50-60 Hz / DC output: +5V / 2A, +12V / 2A)
Raid Level: 0, 1, JBOD
Cooling Fan: 1 x 40mm
Dimensions: 2.56" x 4.72" x 9.06"
