Max Extend Distance: Long range transmission:up to 20 km over a single-mode/Multi-mode LC fiber optic cable;
Specifications: 1080P 120Hz HDMI Extender HDMI Over Fiber Converter 4K@60HZ Video Optical Transceiver LC Single Mode 20km Multimode10G SFP
Video
Standards----------HDMI 2.0b; HDCP 2.2
Maximum pixel clock------600MHz
Maximum data rate-------18Gbps
Resolution ------3840X2160P@60Hz
Connector-----HDMI-A
Fiber type
Fiber interface--------------- LC Connector
Transmission distance--------0~20 km over single/multi-mode fiber
Fiber Type---------- ------------------ Single Mode
Wavelength--------------------1310nm 1510nm
Interface Bandwidth--------------18Gbps
Other
Power supply-----The power adapter: DC 5V/2A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------104*98*23mm
The warranty----...
Specifications: Length of CAT-5E/CAT-6 cable between Rx and TX: up to 120 meters
HDMI input and output : 4K/1080p/720p/576p/576i/480p/ 480i
Support audio format: DTS/Dolby/LPCM
Max bandwidth: 340MHz
Max baud rate: 10.2Gbps
Input HDMI cable distance: =15m AWG26 HDMI standard cable
Output HDMI cable distance: =15m AWG26 HDMI standard cable
TX Max working current: 350mA
RX Max working current : 200mA
Power adapter format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range: (-15 to +55?)
