Specifications: Color: Gray
Humidity: 5% to 95% RH
Interface/Bridge: USB 2.0
Number of Ports: 2
Operating Temperature: 0°C to 55°C (32°F to 131°F)
Storage Temperature: -20°C to 85°C (-4°F to 185°F)
Max Baud Rate: 921.6Kbps
Data Bits: 7, 8
Stop Bits: 1 and 2
Parity: Odd, Even, Mark, Space, and None
Flow Control: Xon/Xoff, Hardware, and None
LED Indicators: 1 - Red - Power LED
Bus Type: USB 2.0
Connector Types: 1 - DB9 Male
Connector Types: 1 - Terminal Block
Connector Types: 1 - USB B Female
Power Adapter Included: Optional
Output Voltage: 5 DC
Output Current: 385mA
Center Tip Polarity: Positive
Plug Type: B
OS Compatibility:
Windows 98SE/ ME/ 2000/ XP(32/64bit)/ 2003(32/64bit)/ Vista(32/64bit)/ Server 2008(32/64bit)/ 7(32/64bit)/ Server 2008 R2, Mac 9.8/OS X, Linux 2.4.x and up;
Wind...
Specifications: Humidity: 0~65% RH
Operating Temperature: 0 to 60 degree C
Storage Temperature: -20 to 80 degree C
FIFO: 512 Bytes
Flow Control: None, Xon/Xoff, RTS/CTS, DTR/DSR
Max Baud Rate:921.6 Kbps
MTBF:30,000 Hours
OS Compatibility:
Windows 7, 8.1, 10
Windows Server 2008 R2, 2012 R2, 2016
Mac OS X 10.11 and 10.12
Linux 2.6.x to 4.4.x LTS Versions only
Type: 8-Port Industrial USB to RS-232/422/485 Serial Adapter
Color: Black
Changer Type: USB to RS-232/422/485 Serial
Specifications: Converts a single USB port into eight RS232/RS422/RS485 serial ports over USB 2.0 with four modes: RS232, RS422, 4-wire and 2-wire RS485
15 kV ESD protection (Level 4) against noise emissions and electrical voltage surges
DIN rail and wall mountable
Rugged IP30 rated metal hub housing and screw-locking host connection, ideal for harsh industrial environments
Data transfer baud rate up to 921.6Kbps
Single USB 2.0 hub port (pass-through) for daisy chaining, or for connecting an additional USB device to the host
COM port expansion with COM retention
Self-powered with included external power adapter
Specifications: Ports: 8
Bus Type: USB 2.0
Port Style: External Hub
Chipset ID: FTDI FT2232H
Performance
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 921.6 Kbps
Serial Protocol: RS-232
Data Bits: 7, 8
FIFO: 4096 byte Transmit and Receive
Parity: Odd, Even, Mark, Space, None
Stop Bits: 1, 2
Specifications: Bus Type: USB 2.0
Chipset ID: FTDI - FT232RL
Interface : Serial
Port Style: External Hub
Ports: 16
Data Bits: 7, 8
FIFO: 256 Bytes
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 480 Mbps
Parity: Odd, Even, Mark, Space, None
Serial Protocol: RS-232
Stop Bits: 1, 2
LED Indicators 16 - Data Receive
16 - Data Transmit
Center Tip Polarity: Positive
Input Current: 1.5 A
Input Voltage: 100 ~ 240 AC
Output Current: 3 A
Output Voltage: 12 DC
Plug Type: N
Power Consumption: 36 W Max.
Power Source: AC Adapter Included
Humidity: 20~80% RH (Non-condensing)
Operating Temperature: -40°C to 85°C (-40°F to 185°F)
Storage Temperature: -65°C to 150°C (-85°F to 302°F)
Enclosure Type: Steel
Changer Type: 1 Port Metal Industrial USB to RS422/RS485 Serial Adapter
Specifications: Color: Black
Connector Type: 1 - USB B Female
Connector Type: 1 - DB9 Male
General Specifications: Dip Switch Configuration
Baud Rate: 300 bps to 921.6 Kbps
Data Bits: 7,8
Isolation: 2500 Vrms
Surge Protection: 500 Watts
Power Requirements: 5V/200mA (USB Bus Powered)
OS Support: Windows 98SE, ME, 2000, XP, 2003, Vista
Specifications: Bus Type: USB 2.0
Interface: Serial
Data Bits: 7, 8
FIFO: 256 Bytes
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 480 Mbps
Parity: Odd, Even, Mark, Space, None
Serial Protocol: RS-232
Stop Bits: 1, 2
LED Indicators: 8 x Data Transmit, 8 x Data Receive
Center Tip Polarity: Positive
Input Current: 1.5 A
Input Voltage: 100 ~ 240 AC
Output Current: 3 A
Output Voltage: 12 DC
Plug Type: B
Power Consumption: 36 W Max.
Humidity: 20 - 80% RH (Non-condensing)
