Specifications: Form Factor: Horizontal
Number of Power Outlets: 8
Rack-Mountable: Yes
Load Capacity: 1920 VA
Maximum Output Voltage: 240V
Maximum Total Current: 20A
Maximum Total Current Draw per Phase: 20A
Nominal Input Voltage: 110V - 240V
Nominal Output Voltage: 110V - 240V
Phase Power: Single phase power adapter
Power Cord Included: 10 ft [3m] C19 to NEMA5-20p
Regulatory Derated Input Current (North America): 16A
Surge Protection: 3600 Joules
Input Connector(s): 1 - IEC C20 (16A, 3 conductor) Power Plug Input
Output Connectors: 8 - IEC C13 (10A, 3 conductor) Power Receptacle Receptacle Output
Input Voltage: 110V - 240V AC
Included in Package
1 x rack-mount PDU
1 x 10 ft [3m] C19 to NEMA5-20p power cord
4 x M5 screws
4 x M5 cage nuts
1 x instruction manual
Specifications: No. of Ports: 12
Pass Through Data Rates 10/100/1000 Mbps
PoE Output:
Pin Assignment and Polarity:
Data Pairs 1/2 (-) and 3/6 (+)
Spare Pairs 7/8 (-) and 4/5 (+)
Output Power Voltage: 54-57V DC
User Port Power: 72W Typ.
Aggregate Power: 1000W
Input Power Requirements:
AC Input Voltage: 100 to 240V AC
DC Input: 57V (RPS or another 9500G midspan)
AC Input Current: 450W Units: 5.5A @ 110V AC; 2.75A @ 220V AC
1000W Units: 12A @ 110V AC; 6A @ 220V AC
AC Frequency: 50 to 60 Hz
Management PowerView Pro included
Indicators:
System Indicator: AC Power (Green)
User Indicator: Channel Power (Green / Orange)
Connectors:
PoE ports and management port: Shielded RJ-45, EIA 568A and 568B
Console Port: USB Connector Type B
DC Connector: DC Block Terminal
RPS Com Connector: HD-D-sub-15
