Specifications: Test Pin Configuration:
- RJ45 EIA, TIA-568A/568B, and crossover cables
- RJ9, RJ11, RJ12, RJ14, RJ25, RJ45, and RJ61
- USOC 2, 4, 6, and 8
- Coax Video-BNC and CATV-F
- USB 3.0, USB 2.0
Transmitter Unit Interface:
- 1 x RJ port
- 1 x USB 3.0/2.0 Type-A port
- 1 x USB 3.0/2.0 Type-B port
- Test button
- Mode button
- On/off button
- LED indicators
- Battery compartment
- Receiver unit attachment port
Power Source
- Transmitter: 9 V DC battery (not included)
- Remote unit: No power needed
Compatibility: Windows 10 (32/64 bit), 8.1 (32/64bit), 7 (32/64bit)
Windows Server 2008 R2, 2012(32/64bit)
Mac OS 10.10 - 10.15
Ports Spec: 2 x 4K DisplayPort (DP) displays (up to 4096 x 2160p @ 60Hz)
1 x USB 3.2 Gen 1 Type-A port (5 Gbps)
1 x Gigabit Ethernet port (with PXE Boot and Wake-on-LAN support)
Specifications: Standard Drive Bays
5.25" Drives: 1
Hotswap 2.5": 2
Slim 5.25" Optical: 1
Indicators HDD Access: blue
Security: Key Lock
Material of Handle: Plastic with Metal Latch
Material of Main Chassis: Stainless & SECC
Dimension: 5.83" x 5.59" x 1.65"
