Ports Spec: Connector Type(s):
1 x DisplayPort (20 pin) Female
1 x HDMI (19 pin) Female
1 x USB 3.0 A (Fast-Charge; 9 pin; SuperSpeed) Female
3 x USB 3.0 A (9 pin; SuperSpeed) Female
1 x RJ-45 Female
1 x 3.5 mm Mini-Jack (4 Position) Female
1 x USB 3.0 B (9 pin; SuperSpeed) Female
1 x Security Lock Slot Female
Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions:
3840x2160 / 2560x1600 / 2560x1440 (DisplayPort - Single Display)
2560x1440 (HDMI - Single Display)
2048x1152 & 2048x1152 (DisplayPort & HDMI - Two Displays)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Compatible Networks: 10/100/1000 Mbps
Auto MDIX: Yes
Full Duplex Support: Yes
Type: Duplicator:
Flash (USB/SD/CF/MS) to Flash (USB/SD/CF/MS), Flash (USB/SD/CF/MS) to Disc (CD/DVD), Disc (CD/DVD) to Flash (USB/SD/CF/MS), Disc (CD/DVD) to Disc (CD/DVD)
Supported Media: USB 1.1, USB 2.0, USB 3.0, USB 3.1, USB 3.2, USB 3+
SD, SDHC, SDXC, SDUC, SD Pro, Mini SD*, Mini SD Pro*, Micro SD*, SD HS, WI-FI SD, Super HS SD
(*Adapter Required)
CF I, CFII, IBM Micro Drive
MS, MS-Duo, MS Pro, MS Pro Duo, MS MagicGate, MS Pro MagicGate, MS-Duo MagicGate,
Specifications: Audio: Yes
Chipset ID: STDP4320
Converter Type: MST Hub
Output Signal: HDMI
Ports: 2
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions:
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.
Average resolution bandwidth allocation
1920 x 1080 (High-definition 1080p) @60 Hz - 22%
1920 x 1200 @60hz - 30%
2560 x 1440 @60hz - 35%
2560 x 1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30 Hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
