Specifications: Note: Some legacy DVI monitors may be limited to a resolution of 1920x1200 when used with this adapter
Maximum Digital Resolutions: 2560 x 1600
Supported Resolutions: 1024 x 768, 1280 x 720 (High-definition 720p), 1920 x 1080 (High-definition 1080p), 1920 x 1200, 2560 x 1440, 2560 x 1600
Connector A: 1 x USB-C (24 pin) Male Input
Humidity: 5 - 90% RH (Non-condensing)
Operating Temperature: 0 to 70 degree C
Storage Temperature: -10 to 80 degree C
Specifications: Maximum Analog Resolutions: 2048 x 1280p @ 60Hz
Maximum Data Transfer Rate: 5 Gbps (USB 3.0)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI / DVI-D / VGA / Mini-DisplayPort
Chipset ID:
Parade - PS176
VIA/VLI - VL102
ITE -IT6516
Audio Specifications: HDMI or mDP output: 7.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz
Maximum Digital Resolutions:
4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz (HDMI)
4096 X 2160 @ 60Hz (mDP)
Supported Resolutions:
Maximum HDMI output: 4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz
Maximum mDP output: 4096 X 2160 @ 60Hz
Maximum DVI and VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0 / DisplayPort 1.2
Wide Screen Supported: Yes
Note: On...
Specifications: Adapter Style: Cable Adapters
Chipset ID: STMicroelectronics - STM32F072CBU6
Converter Type: Cable Adapters
Output Signal: Mini DisplayPort
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 3840x2160 @ 60 Hz
Supported Resolutions:
1024x768
1280x720 (High-definition 720p)
1920x1080 (High-definition 1080p)
1920x1200
2560x1440
2560x1600
3840x2160 (Ultra HD 4K)
Wide Screen Supported: Yes
Connectors:
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B: 1 x Mini-DisplayPort (20 pin) Male Output
Note: Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
Specifications: Maximum Digital Resolutions: 3840 x 2160 @ 60Hz
Supported Resolutions:
3840 x 2160 @ 60Hz
2560 x 1600
2048 x 1280
1920 x 1200
1920 x 1080
1280 x 720
1680 x 1050
1600 x 900
1440 x 900
1360 x 768
1280 x 800
1280 x 768
Wide Screen Supported:Yes
Humidity: 0~90% RH
Operating Temperature: 0 C to 40 degree C
Storage Temperature: -20C to 70 degree C
Output Connector: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
1 x DisplayPort (20 pin) Female Output
Specifications: Supported Resolutions:
1024 x 768
1280 x 720 (High-definition 720p)
1920 x 1080 (High-definition 1080p)
1920 x 1200
2560 x 1440
2560 x 1600
Specifications: 4K Support: Yes
Bus Type: USB-C
Displays Supported: 1
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Maximum Power Delivery Support: 60 W
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
Mac OS 10.9 to 10.12
Chrome OS
Specifications: Audio: Yes
Chipset ID: NXP - PTN5100 / Pericom - PI3DPX1203
Converter Type: Format Converter
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 4K (3840 x 2160) @ 60 Hz
Supported Resolutions:
1024 x 768
1280 x 720
1920 x 1080 @ 144hz
1920 x 1200
2560 x 1440
2560 x 1600
3840 x 2160 @ 60Hz
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Connector:
1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
1 x Mini-DisplayPort (20 pin) Female Output
System and Cable Requirements:
Your USB-C device must support DisplayPort over USB-C (DP alt mode) to work with this adapter
This adapter outputs a single-mode Mini DisplayPort signal and will not work with additional video adapters such as Mini DisplayPort to HDMI, Mini DisplayPor...
Connector Detail: Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B: 1 x DisplayPort (20 pin) Male Output
Note: Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
Specifications: Maximum Data Transfer Rate: 5 Gbps (USB 3.0)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz / 3840 x 2160p @ 30Hz
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Output Connector: 1 x HDMI (19 pin) Female
1 x USB Type-A (9 pin) USB 3.0 Female
1 x USB Type-C (24 pin) USB 3.0 Female
