Specifications: PoE + Data Port (out):
Supports half / full-duplex operation
10/100/1000BASE-T port
IEEE 802.3 compliant
IEEE 802.3u compliant
IEEE 802.3at compliant
IEEE 802.3af compliant
IEEE 802.3ab compliant
Data Port (in):
Supports half / full-duplex operation
IEEE 802.3 compliant
IEEE 802.3u compliant
IEEE 802.3ab compliant
10/100/1000BASE-T port
LED Indicators:
Blue: Power On
Green: Link On
Power:
Power Adapter: 54 V / 0.6 A
Max Consumption: 32.4 watts
Output: 0.6 A at 54 V
Temperature:
Operating: 0 to 50 degree C (32 to 122 degree F)
Storage: -30 to 70 degree C (-4 to 158 degree F)
Humidity:
Operating: 5% to 95% non-condensing
Storage: 5% to 95% non-condensing
Transfer Rate: 1,000 Mbps (IEEE 802.3 compatible)
10/100/1000 BASE-T operation requires the host system to have an SGMII interface with no clocks. With a SERDES interface, this transceiver will operate at 1000BASE-T only.
