Specifications: Data transfer rate: USB 3.1 Gen 2 up to 10Gbps (Compatible with USB 3.1 Gen 1 / 3.0 / 2.0 / 1.1)
LED indicator :
Solid Blue: Powered
Blinking Blue: Reading / writing
Support type of M.2 SSD:
B Key SATA Type M.2 SSD x 1
Support 22mm x 60mm or 22mm x 80mm size
Controller: VIA VL715
Dimensions: 110mm (W) x 9mm (H) x 26mm (D) / 4.33" (W) x 0.35" (H) x 1.02" (D)
Specifications: To take advantage of the increased popularity of M.2 solid state drives, SilverStone created the MS09, a premium, pocketable M.2 enclosure. It has an exquisite anodized aluminum exterior with a size that is nearly as small as common USB thumb drives. Internally, it fits M.2 SATA SSD up to 80mm so the MS09 can be used with a wide variety of new or repurposed M.2 SATA SSD from laptops and turning them into high-speed USB flash drive. To make the most of M.2 SATA SSD’s performance, it also incorporates USB 3.1 Gen 2 interface for superfast read / write and excellent compatibility. Lastly, the MS09 is designed to work without additional driver installation so you can conveniently take it anywhere and use it on nearly any PC instantly.
Data tr...
Specifications: Dimensions: 87.5 x 134 x 18.6 mm
Weight: 181~205g (by capacity)
Standard Compliance:USB 3.0 / 2.0
Data Transfer Rates:Max. 5 Gb/s (USB 3.0 Mode); Max. 480 Mb/s (USB 2.0 Mode)
Power Supply:DC 5V (Power supplied through USB)
Supported Operating Systems:Windows 8 / 7 / Vista / XP / 2000 , Linux 2.6.31 or later, Mac OS 10.5 or later (only USB 2.0 currently supported)
Operating Temperature:5?~ 55?
Storage Temperature:-40?~ 70?
Capacity: 500GB . 1TB . 2TB
Color:Black, White
Three-year warranty
Specifications: Chipset ID: JMicron - JMS580
Drive Size: 22mm - M.2 SATA
Supported Drive Height(s): 2242 / 2260 / 2280
Compatible Drive Types: M.2 (SATA, B-Key, NGFF) / M.2 SATA (NGFF, B+M-Key)
Maximum Data Transfer Rate: 6 Gbps
MTBF: 50,000 hours
TRIM Support:Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
Drive Connectors: 1 - M.2 (SATA, B-Key, NGFF) Receptacle
Host Connectors: 1 - USB Type-C (24 pin) USB 3.1 (10Gbps) Male
Note:
Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
Windows 7 and earlier Windows versions do not support TRIM with USB to SATA devices.
Specifications: Bus Type USB: 3.1 Gen 2
Chipset ID: ASMedia - ASM1352R
Compatible Drive Types: M.2 (NGFF, B-Key)
Drive Installation: Fixed
Interface: USB 3.1 Gen 2
Number of Drives: 2
Supported Drive Height(s): 2230, 2242, 2260, 2280
General Specifications Not compatible with PCI-Express M.2 SSDs
Maximum Data Transfer Rate: 10 Gbps
MTBF: 35,000
Port Multiplier: Yes
Trim Supported: Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
LED Indicators: 2 - Read / Write (green), 2 - Error / Rebuilt (red)
Package Contents: USB 3.0 to M.2 SATA External SSD Enclosure with UASP
1 x USB 3.0 Cable
1 x SSD screw kit
1 x Mini Screw Driver
1 x Instruction Manual
