Specifications: Load Rating: 20 amps @ 120 volts
Maximum Load Inrush Energy: 1400 Joules total during power-up
UL 1449 Adjunct Classification Test Results: 1000 surges, 6000 volts, 3000 amps, B3 pulse; Measured suppressed voltage: 170 volts; no failures
Federal Guidelines: Grade A, Class 1, Mode 1(CID A-A-55818)
EMI/RFI Filter, Normal Mode (50-ohm load): > 30 dB 100 KHz - 50 MHz
EMI/RFI Filter, Common Mode (50-ohm load): > 20 dB 1 MHz - 50 MHz
Under-Voltage Auto Shutdown: Adjustable from 90V to 110V
Over-Voltage Auto Shutdown: Adjustable from 130V to 150V
Endurance (C62.41-1991 Category B3 pulses): 1 kV>500,000; 3 kV>10,000; 6 kV>1000
Control Inputs: Momentary Switch, Latching Switch,Contact Closure or 5-30 Vdc
Input Control Current: 3 mA
DC Voltage Output: 12 Vdc, 40 mA maximum load
Auxiliary Relay Cont...
