Quick View
APC AP9607 Interface Expander SmartSlot CardType: Expansion CardCompatibility: SmartUPS
MatrixUPS
Symmetra Power Array
Silcon UPSSpecifications: Proprietary Slot Type: SmartSlot
Ports: 2 x DB-9 Serial
Temperature:
32°F (0°C) to 95°F (35°C) Operating
5°F (-15°C) to 149°F (65°C) Storage
Humidity:
0 to 95% Relative Humidity Operating
0 to 95% Relative Humidity Storage
Altitude:
0 ftto 10000 ft Operating
0 ftto 50000 ft StorageParts: 2 years limitedModel #: AP9607
Quick View
APC AP9620 Legacy Communications SmartSlot CardType: ModuleCompatibility: UPSSpecifications: Options that provide additional monitoring and control functionality.
Interfaces/Ports Details:
1 x USB USB 2.0
1 x DB-9 Serial
1 x LED
Color: Black
Environmental Compliance: RoHS 7b Exemption,REACH: Contains No SVHCsDimensions: 1.50" x 4.75" x 4.50"Model #: AP9620
Quick View
APC AP9628 5000VA Step-Down Rack-mountable TransformerType: Step Down TransformerSpecifications: Output Connections: 1x Hard Wire 3-wire (H N + G)
Nominal Input Voltage: 208V
Input Frequency: 60 Hz +/- 3 Hz
Input Connections: Hard Wire 3-wire (2PH + G)
Number of Power Cords: 1
Maximum Input Current per phase: 26A
Load Capacity: 5000 VA
Operating Environment: 32 - 104 °F (0 - 40 °C)
Operating Relative Humidity: 0 - 95%
Operating Elevation: 0-10000 feet (0-3000 meters)
Storage Temperature: -13 - 149 °F (-25 - 65 °C)
Storage Relative Humidity: 0 - 95%
Storage Elevation: 0-50000 feet (0-15000 meters)
Regulatory Approvals: CSA, UL 1778, UL ListedDimensions: 3.50" x 17.50" x 24.00" (H x W x D)Weight: 95.00 lbs.Model #: AP9628
Quick View
EATON ASY-0529 9170+ Battery ModuleType: BatteryCompatibility: Powerware UPS:
9170
9170+Specifications: Internal battery type: Sealed, lead-acid; maintenance free
Battery replacement: Hot-swappable
Recharge time: < 4 hours standardDimensions: 4.50" x 7.00" x 14.80"Model #: ASY-0529
