Features: Number of Output Connections:21
3
Form Factor:Zero U
Product Type:PDU
Current:16 A Derated Input Current
16 A Total Current Draw Per Phase
20 A Input Current Per Phase
Form Factor:Zero U Rack-mountable
Input Receptacles:NEMA L6-20P
Product Name:Metered-by-Outlet Rack PDU
Output Receptacles:21 x IEC 60320 C13
3 x IEC 60320 C19
Package Contents:
Metered-by-Outlet Rack PDU
CAN Port Terminator
Installation Guide
Locking Input Power Cord
Rack Mounting Brackets
Safety Guide
Serial Configuration Cable
Features: Package Contents:
Rack PDU 2G, Metered, ZeroU, 23.0kW, 240V, (30) C13 & (12) C19
Installation Guide
Rack Mounting Brackets
Safety Guide
Serial Configuration Cable
Number of Output Connections:12
30
Output Receptacles:12 x IEC 60320 C19
30 x IEC 60320 C13
Power Rating:23 kVA
Power Rating:23 kVA
Current:32 A Derated Input Current
32 A Total Current Draw Per Phase
40 A Input Current Per Phase
Color:Black
Product Type:PDU
Product Name:Rack PDU 2G, Metered, ZeroU, 23.0kW, 240V, (30) C13 & (12) C19
Form Factor:Zero U
Form Factor:Zero U Rack-mountable
Dimensions: 72.0" Height x 2.2" Width x 2.0" Depth
Features: Power Rating:5.76 kVA
Form Factor:Horizontal Rackmount
Toolless-mount
Vertical Rackmount
Product Type:PDU
Color:Black
Power Rating:5.76 kVA
Form Factor:Horizontal Rackmount
Toolless-mount
Vertical Rackmount
Input Receptacles:NEMA L21-20P
Product Name:Metered Rack PDU
Output Receptacles:24 x NEMA 5-20R
6 x NEMA L6-20R
Package Contents:
Metered Rack PDU
Installation Guide
Rack Mounting Brackets
Safety Guide
Serial Configuration Cable
Features: Power Rating:2.88 kVA
Form Factor:Rack-mountable
Vertical
Product Type:PDU
Color:Black
Power Rating:2.88 kVA
Form Factor:Rack-mountable
Vertical
Input Receptacles:NEMA L5-30P
Product Name:Metered-by-Outlet with Switching Rack PDU
Output Receptacles:24 x NEMA 5-20R
Package Contents:
Metered-by-Outlet with Switching Rack PDU
Installation Guide
Rack Mounting Brackets
Safety Guide
Serial Configuration Cable
Features: Package Contents:
Basic Rack 3680VA PDU
Installation Guide
Toolless Mounting Kit
Current:16 A Input Current
16 A Output Current
Number of Output Connections:20
4
Output Receptacles:20 x IEC 320-C13
4 x IEC 320-C19
Power Rating:3.68 kVA
Power Rating:3.68 kVA
Product Name:Basic Rack 3680VA PDU
Color:Black
Input Receptacles:IEC 320-C20
Product Type:PDU
Form Factor:Zero U
Form Factor:Zero U Rack-mountable
Dimensions: 64.0" Height x 2.2" Width x 1.7" Depth
Features: Package Contents:
Rack PDU 2G, Metered, ZeroU, 17.3kW, 240V, (30) C13 & (12) C19
Installation Guide
Rack Mounting Brackets
Safety Guide
Serial Configuration Cable
Number of Output Connections:12
30
Output Receptacles:12 x IEC 60320 C19
30 x IEC 60320 C13
Power Rating:17.30 kVA
Power Rating:17.30 kVA
Current:24 A Derated Input Current
24 A Total Current Draw Per Phase
30 A Input Current Per Phase
30 A Line Current Per Phase
Color:Black
Product Type:PDU
Product Name:Rack PDU 2G, Metered, ZeroU, 17.3kW, 240V, (30) C13 & (12) C19
Form Factor:Zero U
Form Factor:Zero U Rack-mountable
Dimensions: 72.0" Height x 2.2" Width x 2.0" Depth
Features: Power Rating:1.92 kVA
Form Factor:Rack-mountable
Product Type:PDU
Power Rating:1.92 kVA
Form Factor:Rack-mountable
Input Receptacles:1 x NEMA L5-20P
Product Name:Metered Rack PDU
Output Receptacles:24 x NEMA 5-20R
Package Contents:
Metered Rack PDU
Installation Guide
Rack Mounting Brackets
Safety Guide
Serial Configuration Cable
