Protocols: LLDP-MED for VLAN discovery; IPv4; TCP (RFC 793) in SSL/TLS; Domain Name System (DNS): A records (RFC 1706), SRV records (RFC 2782), RTP (RFC 1889, 1890), RFC 5966
Security: HTTPS secure provisioning; Local Access Interface: IVR password
Features: Automatically answer a call by pressing a button on the headset.
Compatibility: Polycom SoundPoint
IP 320
IP 321
IP 330
IP 331
IP 430
IP 450
IP 550
IP 560
IP 650
IP 670
Specifications: Protocol: SIP RFC 3261 Compatible
Ethernet I/F: 10/100 Mbps
Power Input: PoE 802.3af or +5V at 1A
Operating Temperature: -10 degrees C to 50 degrees C(14 degrees F to 122 degrees F)
Payload Types: G711 A-Law and u-Law
Regulatory Compliance: FCC Class A, UL 60950
Security: Media: SRTP
Control: TLS / SIPS / HTTPS
Management: Syslog support, telnet, SSH, remote management using web browser
Ports: Telephone Interfaces: 1 x RJ11 FXS port, One (1) RJ11 FXO PSTN line port with lifeline support
Network Interface: 2 x 10/100 Mbps ports (RJ45) with integrated NAT router
Security: User and administrator level access control, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control
Specifications: Protocol: SIP RFC 3261 Compatible
Ethernet I/F: 10/100 Mbps
Power Input: PoE 802.3af or 48VDC
Operating Temperature: -10 degrees C to 50 degrees C(14 degrees F to 122 degrees F)
Payload Types: G711
Regulatory Compliance: FCC Class A, UL 60950
Page Port Output Balanced 600 Ohm 10 VPP
Line In:
- Input Signal Amplitudes: 2.0 VPP maximum
- Input Impedance:10k ohm
Line Out:
- Output Signal Amplitudes:2.0 VPP maximum
- Output Level: +2dBm nominal
- Total Harmonic Distortion: 0.5% maximum
- Output Impedance: 10k ohm
