Ubiquiti 24W PoE Adapter with Surge and Clamping Protection Peak Pulse Current Gigabit LAN Port (POE-24-AF5X)- Type: PoE Adapter
- Color: Black
- Specifications: Dimensions: 88 x 57 x 33 mm (3.5 x 2.2 x 1.3")
Weight: 159 g (5.6 oz)
Output voltage: 24V DC @ 1.0A
LAN activity indicator: No
Gigabit LAN port: Yes
Remote reset capability: Yes
Reset button: Yes
Rated voltage: 100-240V AC @ 50/60Hz
Input current: 0.6A @ 120V AC, 0.4A @ 240V AC
Inrush current: <60A peak @ 120V AC, <120A peak @ 230V AC
Efficiency: 80+%
Output ripple: 1% Max.
Switching frequency: 65 kHz
Line regulation: <= 3%
Load regulation: <= 5%
2-pair powering: Pins 4, 5 (+) and pins 7, 8 (-)
4-pair powering: -
Storage temperature: -30 to 70°C (-22 to 158° F)
Ambient operating temperature: 0 to 40° C (32 to 104° F)
Ambient operating humidity: 35 to 95% noncondensing
AC connector: IEC-320 C6
Data IN / PoE: RJ45 shielded socket
Surge protection: Difference and common mode
Clamping p...
- Model #: POE-24-24W-G
