Quick View
Cisco Stack Kit, C9200L- Part Number: C9200L-STACK-KIT=
- Type: Stack Kit
- Specifications: Form Factor : Plug-in Module
Supported Device : Designed For CISCO Catalyst 9200l
Connectivity Technology : Wired
Performance (bandwidth) : 80 Gbps
Interfaces : 80 Gbps
- Model #: C9200LSTACKKIT

Quick View
TRENDnet TC-P16C6AS (V1.0R) 16-Port Cat6A Shielded 1U Patch Panel- Type: Other
- Specifications: Standards
ANSI/TIA/EIA-568-B.2-1
ANSI/ TIA/EIA-310-D
EN50173-1: 2002
ISO/IEC 11801 2nd edition: 2002
Interface
16 x RJ-45 ports with 50 micron gold-plated 8P/8C contacts
T568A/T568B wiring cards for Krone 110 termination with color-coded wiring diagram
90 degree IDC terminals
Compatible with 22 – 26 AWG solid or stranded wire
Integrated cable management
SGCC steel construction
18 AWG grounding wire with screw terminal
Electrical Specification
Insulation resistance: >= 500M Ohms
Dielectric Withstand Voltage: 1000V DC
Contact resistance: <= 20M Ohms
Current rating: 1.5A at 20 degree C (68 degree F)
Mechanical Specification
Contact force 99.2g (3.5 oz.)
Plug retention force: 13.3kg (29.00 lbs.)
110/ Krone IDC insertion force: min. 4.5kg (9.90 lbs.)
110/ Krone IDC retention force: min. 0.5kg (1.10 lbs.)
Dimensions: 1.75" x 17.30" ...
- Model #: TC-P16C6AS (V1.0R)
