Planet LRP-101C-KIT 1-Port Long Reach PoE Over Coax Extender Kit (LRP-101CH + LRP-101CE)- Type: PoE Extender
- Color: Black
- Specifications: Ethernet Interface: LRP-101CH
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI/MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both Mid-span and End-span PSE Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LRP-101CE
Copper: 10/100BASE-TX RJ45, Auto-negotiation / auto-MDI/MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PSE (Power Source Equipment)
PoE Output: 56V DC, 600mA max.
PoE Budget: Up to 25 watts
PoE Mode: End-span, RJ45 Pin 1/2 (+), 3/6 (-)
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LED Indicators:
LRP-101CH
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACT
LRP-101CE
4 x LEDs
PWR
LRP LNK
PoE-in-us...
- Model #: LRP-101C-KIT
