Frequency Band: Frequency Band: 2.4 GHz, 5 GHz
Performance: Maximum data rate (5 GHz): 1200 Mbps ¦ Maximum data rate (2.4 GHz): 574 Mbps
Capacity: Concurrent users: 256 ¦ Maximum number of configured SSIDs: 16
Interface: 1 x 1000Base-T (PoE) - RJ-45 ¦ 1 x USB 2.0 - Type A
Standards: IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n, IEEE 802.11k, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ac Wave 2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, UL 2043, RoHS, EN 60950-1, WEEE, EN 60601-1-2, EN 62311, EN 50121-4, IEC 61373, EN 50121-1, ISTA 2A
Frequency Band: AP type: Outdoor, tri radio, 2.4GHz, 5GHz and 6GHz (concurrent) 802.11ax 2x2 MIMO; 2.4 GHz radio: Two spatial stream Single User (SU) MIMO for up to 574 Mbps wireless data rate with 2SS HE40 802.11ax client devices; 5 GHz radio: Two spatial stream Single User (SU) MIMO for up to 1.2 Gbps wireless data rate with 2SS HE80 802.11ax client devices; 6 GHz radio: Two spatial stream Single User (SU) MIMO for up to 2.4 Gbps wireless data rate with 2SS HE160 802.11ax client devices; Up to 512 associated client devices per radio, and up to 16 BSSIDs per radio (limited to 8 for the 6GHz radio)
Interface: (1) 10/100/1000BASE-T RJ-45 port, auto-sensing link speed and MDI/MDX
(1) SFP Fiber port
Frequency Band: Dual radio for simultaneous dual-band operation
5 GHz 802.11ax 4x4 MIMO for up to 4.8 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
Antenna: Down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.77 dBi in 2.4GHz and 4x4 MIMO with peak antenna gain of 4.55 dBi in 5GHz (of the effective, combined pattern for both antennas in each band)
LAN Ports: Uplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3at)
DC power connector (12V) Bluetooth
Low Energy (BLE) radio LED status indicators
Reset/LED control button
Kensington security slot...
Wireless Data Rates: Max bandwidths and peak data rate per band: 20/40 (2.4 GHz), 20/40/80/160 (5 GHz), 20/40/80/160/320 (6 GHz), maximum peak data rate 14.4 Gbps
Frequency Band: 2.4 GHz + 5 GHz + 6 GHz or 5 GHz + 5 GHz + 6 GHz or 5 GHz + 6 GHz + 6 GHz
Interface: Ports: E0, E1: Two Ethernet wired network ports (RJ45) U0, U1: Two USB 2.0 host interfaces (Type A connector) Kensington security slot Serial console interface (proprietary, microB USB physical jack)
Wireless Data Rates: Max bandwidths and peak data rate per band: 20/40 (2.4 GHz), 20/40/80/160 (5 GHz), 20/40/80/160/320 (6 GHz), maximum peak data rate 14.4 Gbps
Frequency Band: 2.4 GHz + 5 GHz + 6 GHz or 5 GHz + 5 GHz + 6 GHz or 5 GHz + 6 GHz + 6 GHz
Interface: Wired network interface: 2 x 5GbE
Ports: E0, E1: Two Ethernet wired network ports (RJ45) U0, U1: Two USB 2.0 host interfaces (Type A connector) Kensington security slot Serial console interface (proprietary, microB USB physical jack)
