Specifications: HARDWARE FEATURES
DDM: Yes
SFP-MSA: Yes
Hot Swappable: Yes
MEDIA CONVERTER & MODULE
Standards and Protocols: IEEE 802.3z, TCP/IP
Wave Length: TX 1310 nm, RX 1550 nm
Power Supply: 3.3 V
Safety & Emission: FCC, CE
Cabel: Single-Mode Fiber
Fiber Type: 9/125 µm Single-Mode
Max. Cable Length: 2 KM
Data Rate: 1.25 Gbps
Port Type: LC Simplex
Environment:
- Operating Temperature: 0-70 °C (32-158 °F)
- Storage Temperature: -40-85 °C ( -40-185 °F)
- Operating Humidity: 10-90% RH, Non-Condensing
- Storage Humidity: 5-90% RH, Non-Condensing
Features: Designed for on-site gigabit fiber communication
Up to 2 km transmission distance with 9/125 µm SMF (Single-Mode Fiber)
Bidirectional WDM communication on a single fiber
Compatible with Small Form Pluggable Multi-Source Agreement (SFP-MSA)
Supports Digital Diagnostic Monitoring (DDM)
Hot-swappable module desi...
Specifications: Standards and Protocols: IEEE Std 802.3, 802.3ab, 802.3bz, 82.3an
Power Supply: 3.3V
Max. Cable Length:
- 100BASE-TX: UTP cat .5 or above (max. 100m)
- 1000BASE-T/2.5GBASE-T/5GBASE-T: UTP cat.5e or above (max. 100m)
- 10GBASE-T: UTP cat.6a or above (max. 30m)
Data Rate: 10.3 Gbps
Port Type: 1 x 10G RJ45 Port
Safety & Emission: FCC, CE, RoHS
Environment:
- Operating Temperature: 0 - 70 °C (32 - 158 °F)
- Storage Temperature: -40 - 85 °C (-40 - 185 °F)
Features: Support 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T, and 100BASE-TX
Transmit data up to 30m* at 10 Gbps (UTP cat.6a or above)
Support DDM (Temperature and Voltage)
Hot-Pluggable SFP+ Footprint Features
Support TX Disable function
Commercial Product Operating Temperature Range: 0-70°C
Fully Metallic Enclosure for Low EMI
Specifications: Ethernet:
Ethernet Ports: 5
Ethernet Speed: 10/100 Fast Ethernet
PoE: PoE+ 802.3at Type 2
Power:
Power Input: 44V - 57V DC Redundant DC Dual Power Inputs, reverse polarity protected
PoE Power Budget: 90W @ 70?
General:
Operating Temperature Range: -40°C to +70°C / -40°F to +158°F
Storage Temperature: -40°C to +85°C / -40°F to +185°F
Form Factor: Embedded
Power Consumption: 4 Watts Max : 91mAmps@+44VDC/70mAmps@+57VDC
Features: Allows power and data to be combined on the same Ethernet cable
Ports 1-4 PoE+ capable
Fully compliant to IEEE 802.3af/at
PoE Power Budget: 90W @ 70°C
Redundant dual power inputs: +44V to +57V DC
Industrial operating temp range -40°C to +70°C / -40°F to +176°F
