Specifications: Audio: Yes
AV Input: HDMI
AV Output: HDMI
Cabling: Cat 6 UTP
Chipset ID: Norelsys NS 5730, NS5731
Audio Specifications: 7.1 Surround Sound
Max Distance: 140 m / 460 ft
Wide Screen Supported: Yes
Supported Resolutions:
3840x2160 (4K) 60Hz
2560x1600 60Hz
1920x1200 60Hz
1920x1080 (1080p) 60Hz
1280x720 (720p) 60Hz
*Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Center Tip Polarity: Positive
Input Voltage: 110V-240V AC
Output Current: 3 A
Output Voltage: 5V DC
Plug Type: M
Power Source: 2 AC Adapters Included
Max Extend Distance: CATx: 328 feet. (100 m); single-mode fiber (SFP): up to 30 km
Color: Black
Specifications: HDMI 4K video over IP
This attractively priced IP video distribution solution uses existing standards-based Ethernet technology and TCP/IP protocols to unicast HDMI 4K video signals on your Gigabit Ethernet network. In a multicast configuration, one transmitter can drive multiple receivers with no extra network load.
Plug-and-play setup
Because the transmitter and receiver install directly into your existing LAN infrastructure, integration is easy. And you don't have to configure any IP settings. Connect your source, your display, a network switch, and you're ready go.
PoE support for remote powering
The MediaCento IPX 4K is PoE powered eliminating the need for power supplies. Using a PoE netwo...
Specifications: Audio Specifications: 7.1 surround Sound
Max Distance: 35 m / 115 ft
Maximum Cable Length: 114.8 ft [35 m]
Maximum Digital Resolutions: 1920 x 1080 at 60Hz
Supported Resolutions: 1920 x 1080, 1680 x 1050, 1600 x 900, 1440 x 900, 1360 x 768, 1280 x 800, 1280 x 768, 1280 × 720
Wide Screen Supported: Yes
System and Cable Requirements:
The HDMI cable connected to your video source must be longer or equal to the length of the cable connected to your display.
The maximum supported video source cable length is 82 ft. (25m).
The maximum supported display cable length is 33 ft. (10m).
LED Indicators:
1 - power LED (blue)
1 - video source LED (blue)
Specifications: Audio Specifications; DTS / Dolby Digital
Bandwidth: 18Gbps
Max Distance: 14 m / 45 ft
Video Revision: HDMI 2.0
Wide Screen Supported: Yes
Plug Type: USB Micro-B
Power Consumption (In Watts): <2.5
Power Source: Not Included (not required for standard applications)
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 1
Video Ports : HDMI (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 2.2
Supported Resolutions: 1280 x 720 (720p); 1920 x 1080 (1080p); 3840 x 2160 (4K)
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Max. Distance (Between any 2 Units): 230 ft.
Maximum Distance with Booster: 400
Receiver/Transceiver Video Output: HDMI
Receiver - Number of Video Outputs: 1
Max Supported Color Depth: 36-bit Deep Color
HDR Support: Yes
3D Video Supported: Yes
Chroma Sub Sampling: 4:4:4
Maximum Signal Range (m): 70
HDCP Specification: 2.2
Driver Required: No
Recommended Category Cable: 26AWG STP Cat6/6a
EMI/RFI Line Noise Protection: Yes
DIN Mountable: No
Integrated/Removable Cable: No
Includ...
Specifications: Voltage Compatibility (VAC): 100; 110; 120; 125; 127; 200; 208; 220; 230; 240
External Power Supply Input Specs (V / Hz / A): 100-240V~50/60Hz, 0.2A
External Power Supply Output Specs (V / A): 5V / 1A
External Power Supply Cord Length (ft.): 5
External Power Supply DC Barrel Connector Specs: OD: 5.5 x 2.1 x 10mm, Positive Pin, Negative Sleeve
External Power Supply Plug(s): NEMA 1-15P North America
External Power Supply Certifications: UL; cUL
Bus Powered: Yes
Max Supported Video Resolution: 4K x 2K (3840 x 2160) @30Hz
HDMI Specification: 1.4
HDCP Specification: 2.2
Audio Specification: Supports 7.1-channel LPCM, DTS-HD and Dolby-AC3 digital audio
System Requirements:
Source device with HDMI output (Blu-ray player, cable box, laptop)
Display device with H...
