Converter Type: Async RS232 to RS422/485 Interface Converter
Feature: Transmit data up to 115 kbps or at distancesup to 4000 ft.
Operates in point to point or multipoint applications
Operates 2-wire half-duplex or 4-wire half- or full-duplex.
async (data leads) only.
Up to 32 RS485 devices can be attached to create a large multi-drop network
The RS485 driver is automatically enabled during each spacing state on the RS232 side.
Format: SD Format Support
525/29.97 NTSC, 625/25 PAL
HD Format Support
720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080PsF23.98, 1080p24, 1080PsF24, 1080p25, 1080PsF25, 1080p29.97, 1080PsF29.97, 1080p30, 1080PsF30, 1080p50, 1080p59.94, 1080p60
2K Format Support
2048x1080PsF23.98, 2048x1080p23.98, 2048x1080PsF24, 2048x1080p24, 2048x1080PsF25, 2048x1080p25
4K Format Support
3840x2160p23.98, 3840x2160p24, 3840x2160p25, 3840x2160p29.97, 3840x2160p30, 4096x2160p24
SDI: SDI Video Rates
SDI video connections are switchable between 6G-SDI, HD and SD-SDI
SDI Video Sampling
4:2:2 and 4:4:4
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2 and 4:4:4
SDI Color Space
YUV and RGB
SDI Auto Switching
Automatic...
