Specifications: Hardware
Audio: Yes
Performance
Maximum Digital Resolutions: 1920 x 1080 (1080p) at 60Hz
Supported Resolutions: 1920 x 1080, 1680 x 1050, 1600 x 1200, 1600 x 900, 1440 x 900, 1366 x 768, 1280 x 1024, 1280 x 720, 1024 x 768
Wide Screen Supported: Yes
Indicators
LED Indicators: 1 x status LED
Power
Power Source: USB-Powered
Environmental
Humidity: 0~80% RH
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Physical Characteristics
Enclosure Type: Steel
Product Height: 0.87"
Product Length: 3.15"
Product Width: 2.05"
Product Weight: 5.36 oz.
Package Contents: 1 x EDID emulator
1 x USB power cable
1 x screw driver
4 x foot pads
1 x quick start guide
Specifications: Maximum Resolution:3840 x 2160
DisplayPort:Yes
HDMI:Yes
VGA:Yes
Package Contents: Multi-input to HDMI Automatic Switch and Converter - 4K
1 x IR Remote Control
1 x Screw Kit
1 x Mounting Bracket Kit
1 X Footpad Set
1 x RJ11-to-RS232 Converter
1 x RJ11 Cable
1 x Universal Power Adapter (NA / EU / UK / AU)
1 x Quick Start Guide
Specifications: Video Resolution: 480p, 720p, 1080i and 1080p with 3D support
Video Streaming: <1ms Latency
Frequency: 4.9 ~ 5.9 GHz (Includes Non-DFS and DFS Frequency Bands)
Range: Maximum video transmission range is 30 ft. (10m)
LEDs
Power On: Transmitter: 1 x Blue LED; Receiver: 1 x LED (two-tone: green & red)
Power
Amps: 1A (Transmitter) and 1.5A (Receiver)
Voltage: 5V DC Mini USB (Transmitter and Receiver)
1 x Mini USB Power Jack (Transmitter and Receiver)
Operating Temperature: 0 ~ 40°C
Unit Dimensions: 0.75" x 1.12" x 3.12"
Weight: 1.55 lbs.
Interface: HDMI
Audio: Audio Output:
Digital 6Mbps, 2 to 8 channels 16 ~ 24 bits/sec by I2S and S/P DIF bus over WHDI transmission (Dolby Digtial & DTS)
Specifications: Weight & Size:
Weight: 4.83 oz.
Height: 1.57 in
Width: 1.57 in
Depth: 6.50 in
Storage:
8GB*
* Portion of storage occupied by system software
Expandable via microSD
Wireless:
802.11ac 2x2 MIMO 2.4 GHz and 5 GHz Wi-Fi
Bluetooth 5.0 + LE
Captive Portal support
Software Updates:
SHIELD Experience Upgrades directly from NVIDIA
Voice Assistants:
Built in Voice Control
The Google Assistant
Hands-free Voice Control
Google Home compatible (Google Assistant)
Amazon Echo compatible (Works with Alexa)
Power:
Built-in power supply
Gaming Features:
NVIDIA GeForce NOW game streaming service (compatible game controller or keyboard/mouse is required)
NVIDIA GameStream (requires compatible GeForce RTX or GTX-powered PC)
Android gaming via Google Play Store
Included Apps:
NVIDIA Games
Netflix
YouTube...
Others: Single VGA output connector, on a compatible system
Graphics hardware and display driver supporting a 2048 x 768 or 2560 x 1024 resolution
Specifications: Automatically detected display modes*:
1920 x 480 (3 x 640 x 480) @ 60Hz to 3840 x 1024 (3 x 1280 x 1024) @ 60Hz
Additional display modes enabled by running TripleHead2Go Mode Expander software:
2560 x 1024 (2 x 1280 x 1024) @ 60Hz to 3840 x 768 (2 x 1280 x 768) @ 60Hz
* GPU dependent
EMC certifications: Class B - CE, CSA, FCC, VCCI
Connector box size (width x height x depth): 4.2" x 1.0" x 3.6"
