Front Panel LEDs: 16 power availability LEDs confirm power off/on status for each built-in outlet. Two additional LEDs with toggle button identify which bank the visual current meter is reporting (bank 1, bank 2 or bank 1&2 combined)
Certifications: Tested to UL 60950-1 (USA, Canada), Class A (Emissions), NOM (Mexico)
Certifications: Tested to UL60950-1: 2007 R12.11 (USA), CAN/CSA-C22.2 NO. 60950-1-07+A1: 2011(Canada), FCC CLASS A PART 15 (Emissions), NOM (Mexico), RoHS compliant, TAA Compliant
Specifications: Output
Output Connections:
(1) NEMA L14-30R
(2) NEMA L5-20R
Input
Nominal Input Voltage: 208V
Number of Power Cords: 1
Regulatory Approvals: CSA,UL 1778
Specifications: Output:
Nominal Output Voltage: 100V, 120V
Maximum Total Current Draw per Phase: 30A
Output Connections: (6) NEMA 5-15R, (2) NEMA 5-20R
Overload Protection: Yes
Cord Length: 10 ft (3.05 meters)
Input:
Nominal Input Voltage: 100V, 120V
Input Frequency: 50/60 Hz
Input Connections: NEMA L5-30P
Cord Length: 10 feet (3.05 meters)
Number of Power Cords: 1
Maximum Line Current per phase: 24A
Maximum Input Current per phase: 24A
Load Capacity: 3000 VA
Load Power Factor Range: 0 to 1
Color: Black
