Specifications: Interface: SATA
Connector Type(s): RJ-45
Enclosure Type: Steel
Package:
1 x Dual 2.5" Mounting Bracket
1 x SATA Power Y cable
2 x SATA DATA Cable
Specifications: All in One Solution to Connect to Different Types of Interface's Hard Drive
This USB 3.0 to SATA IDE Adapter connects any standard 2.5in or 3.5in SATA or IDE hard drive to a computer through an available USB 3.0 port, also supported DVD-ROM, CD-ROM, CD-RW, DVD-RW, DVD+RW; Backward compatible with USB 2.0/1.1.
Supported Drives: 2.5"/3.5" SATA HDD/SSD; 2.5"/3.5" IDE HDD; DVD-ROM, CD-ROM, CD-RW, DVD-RW, DVD+RW.
Compatible with Windows 10/8/8.1/7/Vista/XP and Mac OS, Linux, and Chrome OS etc.
Data Transfer Rate: up to 5Gb/s (10 times faster than USB 2.0).
Supports drives with a capacity of up to 6TB.
Backward compatible with USB 2.0/1.1.
DC Power Supply 12V included for 3.5" devices.
On/Off Switch for HDD protection.
Pluy & Play, reliable and stable.
Package Contents: 1 x Mounting All Screws Needed, 1x 4 Pin to Dual 15 Pin SATA Power Cable 2x SATA Data Cables( 18 inch),one is straight to straight, the order is straight to 90 degree
Specifications: Color: Black Nickel
Material: 1.0 mm SPCC with nickel plating
Application: 3.5" drive internal bay
Capacity: 2 x 2.5" hard drives
Overall Dimension: 101.6 mm (w) x 25.4 mm (h) x 146 mm (d)
Weight: 160g
Specifications: Includes 1 x Combined 7+15 pin SATA plus LP4 Power to SATA Cable
Connectors 1x SATA 7 pin Female Connector
Connectors 1x SATA 15 pin Female Connector
Connectors 1x LP4 Male Connector
Specifications: Bus Type: USB 3.1 Gen 2
Chipset ID: ASMedia - ASM1351
Compatible Drive Types (Type and Rate): SATA
Drive Size: 2.5in & 3.5in
Interface : USB 3.1 Gen 2
Number of Drives: 1
Hot Swap Capability: Yes
Max Drive Capacity: Currently tested with hard drives up to 6TB
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
LED Indicators: 1 - Power and Activity
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 110 ~ 240 AC
Output Current: 2.0 A
Output Voltage: 12 DC
Plug Type: M
Power Source: AC Adapter Included
Specifications: Interface: USB 3.0 & eSATA
Number of Drives: 2
Drive Size: 2.5in & 3.5in
Drive Type: SATA
Drive Installation: Removable
Chipset ID: JMicron - JMS562
Drive Connectors: 2 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors:
1 - eSATA (7 pin; Data) Female
1 - USB 3.0 B (9 pin; SuperSpeed) Female
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Type and Rate: SATA III (6 Gbps)
Max Drive Capacity: Currently tested with up to 4TB 7200 RPM 3.5" hard drives per bay (8TB total) and 2TB 5900 RPM 2.5" hard drives (2TB total)
Insertion Rating: 15,000 Cycles
Specifications: Device Support: SATA III/II/I HDD or SSD or Hybrid
Device Size: 3.5" or 2.5" SATA HDD/SSD/Hybrid
Internal Interface: Standard SATA
External Interface: USB 3.1 Type C
Interface Cable x2:
USB Type-C to Type-C (for system with Type-C port)
USB Type-C to Type-A (for system with Type-A port)
USB cable Length: 30 inches / 800mm each
HD Capacity: Up to 12TB
Material: Aluminum Casing, ABS Tray
AC Adapter Output: 12VDC, 2A.
Specifications: Sigle bay 2.5" HDD/ SSD bracket Supports 2.5" HDD/SSD into 3.5" PC Bay Eight (8) screws included. Black Metal material Product Size: 3.94" x 4.72" x 0.59"
