Specifications: Cable Requirements: Twisted pair: CAT5 or above, shielded or unshielded;Singlemode fiber: 50-/125-µm or 62.5-/125-µm duplex
Humidity: 5 to 95%, noncondensing
MTBF: 109k hours
Operating temperature: +32 to +122°F (+0° to +50°C)
Power: From the included external 100-240-VAC, 50-60-Hz adapter;Via USB Power Adapter Cable (LHC021A) connected to a computer's USB port;From the PowerTray with a 100-240 VAC, 50-60 Hz (LHC018A-AC-R2) power supply
Storage temperature: 0 to 160°F (-20 to +70°C)
Ports: SW1 (TP1): Auto-Negotiation On/Off
SW2 (TP1): 10Mbps or 100Mbps with Auto-Negotiation Off
SW3 (TP1): Half or Full-duplex with Auto-Negotiation Off
SW4 (Fiber1): Half or Full-duplex
SW5: AutoCross On/Off
SW6 (xBFTF10xx-10x): Link Pass Through On/Off
SW7 (TP2): Auto-Negotiation On/Off
SW8 (TP2): 10Mbps or 100Mbps with Auto-Negotation Off
SW9 (TP2): Half or Full-duplex with Auto-Negotiation Off
SW10 (TP2): Monitor On/Off
Transfer Rate: 10/100 Mbps
LEDs: PWR (Power): On = connection to external power
FD (Fiber Duplex): On = Full-duplex; Off = Half-duplex
LACT (Fiber Link/Activity): On = Link; Blinking = Activity
Duplex/Link (Copper): On (Yellow) = Half-duplex Link;Blinking (Yellow) = Half-duplex Activity
On (Green)= Full-duplex Link;Blinking (Green)= Full-duplex Activity
Speed (Copper): Yellow= 10...
