Specifications: Chipset ID: JMicron JMB394 + JMS539
Color: Black
Drive Connectors: 4 - SATA Data & Power Combo (7+15 pin) Receptacle
Drive Size: 2.5in / 3.5in
Drive Type: SATA
Enclosure Type: Plastic
Fans: 2 - 60 mm
Host Connectors: 1 - eSATA (7 pin; Data) Receptacle
Host Connectors: 1 - USB 3.0 B (9 pin; SuperSpeed) Female
Input Voltage: 110 ~ 240 AC
Insertion Rating: 15,000 cycles per bay
LED Indicators: 4 - Drive Power/Activity
Max Drive Capacity: Tested up to 3.0 TB
Number of Drives: 4
OS Compatibility: Windows 2000/ XP(32/64-bit)/ Server 2003(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-bit)/ Server 2008 R2, Mac OS X, and Linux
Output Current: 6500mA
Output Voltage: 12 DC
Port Multiplier Support: Yes
Power Adapter Included: Yes
Type and Rate: SA...
Specifications: Chipset: ASMedia 2364
Compliant with USB 3.2 Gen 2x2 specification revision 1.0
Compatible with PCIe 3.0 x 4 specification
USB data transfer rate: Up to 20Gbps
SSD type (not included): M.2 PCIe NVMe SSD (M Key). Note: Not compatible with M.2 SATA SSDs
SSD size: 2230 / 2242 / 2260 / 2280mm
Power source: USB-C Bus-powered (5V)
UASP: Yes
Hot plug: Yes
Specifications: Data transfer rate: USB 3.1 Gen 2 up to 10Gbps (Compatible with USB 3.1 Gen 1 / 3.0 / 2.0 / 1.1)
LED indicator :
Solid Blue: Powered
Blinking Blue: Reading / writing
Support type of M.2 SSD:
B Key SATA Type M.2 SSD x 1
Support 22mm x 60mm or 22mm x 80mm size
Controller: VIA VL715
Mobile Rack Drives Support: 1 x 2.5" Drive to 5.25" Bay
Mobile Rack Interface: Host Interface : 1 x Slimeline SATA 7pin
Drive Fit : 1 x 2.5" SATA SSD/HDD (up to 7mm height)
Device Fit : 1 x Ultra Slim ODD bay (9.5mm height)
Specifications: RoHS Compliance: Yes
Standard Drive Bays:
5 x 3.5" Hotswap
3 x 5.25" Drives
Hotswap HDD Type: 2.5" & 3.5" SAS I/II/III & SATA I/II/III
Indicators: Power, HDD, fan, and high temperature
Material of Front Bezel: Aluminum
Material of Handle: Aluminum
Material of Main Chassis: Aluminum Design with Conductive Dissipation Grooves
Color of Front Bezel: Red
Color of Main Chassis: Black
Package Content: SATA Cable Included (5pcs)
Cooling Fan: 1 x 80mm
Dimensions: 4.96" x 5.75" x 8.25"
Specifications: RoHS Compliance: Yes
Standard Drive Bays:
5 x 3.5" Hotswap
3 x 5.25" Drives
Hotswap HDD Type: 3.5" SAS I/II/III & SATA I/II/III
Indicators: Blue for Power on / Purple for HDD Access
Security: Key Lock
Material of Front Bezel: Aluminum
Material of Handle: Aluminum
Material of Main Chassis: Aluminum
Color of Front Bezel: Blue
Color of Main Chassis: Black
Cooling Fan: 1 x 80mm
Dimensions: 4.92" x 5.71" x 7.79"
